Chapter 1 Specification - SOLTEK SL-B8E-FG Manual

Table of Contents

SL-B8E-FG / B8E-FGR

Chapter 1 Specification

This series of mainboards features an integration of the powerful pro-

cessor Intel Pentium 4 and the North Bridge Intel 865G. The Intel P4

processor is a rapid execution engine supporting 800/533/400MHz sys-

tem bus, while North Bridge Intel 865G is a high performance integrated

chipset providing Dual Channel DDR 400/333/266 SDRAM memory

interface, Hub interface, AGP interface as well as an integrated Graph-

ics Port for VGA display.

Integrated with i865G, South Bridge Intel ICH5/ICH5R supports the

LPC I/O, upstream Hub interface, PCI interface, IDE interface, Serial-

ATA /SATA RAID, USB 2.0 interface, and interrupt control. (The differ-

ence between ICH5 and ICH5R is the RAID interface support). And the

8-channel Audio support is also integrated via the on-board chip ALC850.

This chapter is to introduce to users every advanced function of this

high performance integration.

Topics included in this chapter are:

1-1 Mainboard Layout

1-2 Mainboard Specifications**

1-3 Mainboard Specification Table

1-4 Chipset Diagram

** If any difference is found between the mainboard description

and the Mainboard you are using, please look up the Errata/

Update Slip enclosed inside for the correction or updated

information, or else contact the mainboard Dealer or visit our

Web Site for the latest manual update.
