1-2.4 Memory

2 DDR DIMM 184-pin slots on board :
• Supporting unregistered, non-ECC Dual-channel DDR 400/333/266
SDRAM to 2GBs
• DIMMs to be populated in identical pairs for Dual-channel operation
• SPD (Serial Presence Detect) Scheme for DIMM Detection supported

1-2.5 Integrated Multiplexed AGP and DVO Interface

Integrated multiplexed AGP and DVO interface in Springdale-G,sup-
porting AGP performance and analog/Digital display:
• One AGP slot on board, supporting both Digital Video Out card or
AGP8x/4x card for analog/digital display (TMDS,LVDS and TV-out)
(See AGP Installation in Chapter 2 of this manual)
• One 15-pin VGA connector on board, supporting analog display
• Hardware motion compensation for software MPEG/DVD decode
• Integrated 2D/3D graphics accelerator
• VGA Driver enclosed in Support CD for user's installation

1-2.6 Multi-I/O Functions

• Serial ATA Controller integrated in ICH5, supporting:
-- 2 Serial ATA connectors supporting up to 150MByte/s transfer rate
• Serial ATA RAID Controller integrated in ICH5R, supporting:
-- 2 SATA/SATA RAID connectors supporting up to 150MByte/s transfer rate
• PCI EIDE Controller, supporting:
-- 2 UATA100/66/33 IDE connectors supporting up to 4 IDE devices
• Dedicated IR Functions:
-- Third serial port dedicated to IR function either through the two
complete serial ports or the third dedicated port Infrared-IrDA (HPSIR)
and ASK (Amplitude Shift Keyed) IR
• Multi-mode Parallel Data Transfer:
-- Standard mode, high speed mode ECP and enhanced mode EPP
• Floppy Disk Connector:
-- 1 FDD connector supporting 2 floppy drives with drive swap support
• Universal Serial Bus Transfer Mode:
-- USB V2.0 compliant; 480Mb/s USB Bus, supporting Windows 2000 or
later operating systems (no support for Win 9X/Me)
-- 4 built-in USB Ports and 2 USB Headers which require 2 additional
USB cables to provide 4 more optional USB ports
• PS/2 Keyboard and PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- 1 serial ports on board
Chapter 1 Specification
11
