Appendix B Adjusting Input settings

Source settings

Option
Inputs
Select an input
Screen brightness
Volume

Advanced settings

Access the current input's advanced settings by tapping the three dots ••• that appear in upper right
corner of the input settings menu screen. The current input is surrounded by a green circle
Tip
You can also open the Advanced settings menu by pressing the Settings button
control when viewing any input other than Android.
Option
Audio
Note
The following settings are applicable to all inputs.
Volume
Bass
smarttech.com/kb/171861
Values Function
PC Select a connected computer or
other device's input to view on the
Android
display.
HDMI1
Note
HDMI2
HDMI3
The PC input appears only when
Type-C1
an OPS PC module is installed in
the display's accessory slot.
Type-C2
DP
VGA
Range slider Sets the overall brightness of the
image.
Range slider Sets the display's volume.
Values Function
1 to 100 Sets the display's volume
-5 to 5 Sets the bass level.
Notes
A green circle appears around
the currently selected input (PC,
Android, HDMI1, HDMI2, HDMI3,
Type-C1, Type-C2, DP, or VGA).
Inputs with a connected source have
a green dot beside the input name,
rather than a gray dot. The input
name also appears in green text
rather than gray when an input is
connected.
Note
Disabled inputs do not appear in
the list of available inputs.
[N/A]
[N/A]
.
on the remote
Notes
[N/A]
This setting is only adjustable when
Custom audio mode is enabled (see
Audio modes below).
87
