12.Parameter setting
1. Parameter setting table
Model
ARVHD-H220NR1DC
ARVHD-H280NR1DC
ARVHD-H220/4R1B
ARVHD-H280/4R1B
ARVHD-H112/4R1A
ARVHD-H125/4R1A
ARVHD-H140/4R1A
ARVHD-H150/4R1A
1. 0508 menas capacity is 8 kbtu/h , 0524 means capacity is 24 kbtu/h ,
2. 0900 menas room card function invalid, 0901 means valid
3. 1501 means choose wired controller built in temperature sensor as the detect temperature value
1500 means choose return air temperature sensor as the detect temperature value
Note: Once PCB be replaced , please recheck the parameter value ,ensure keep same as default
parameter value
– DC&AC TYPE
Parameter No. & definition
Capacity
IDU type
Parameter
04
35
35
35
35
2
2
2
2
238
Technical&Service Manual
Room card
05 09
80 00
100 00
80 00
100 00
36 00
45 00
50 00
60 00
Room sensor
selection
15
01
01
01
01
01
01
01
01
