  • Page 1 OWNER’S MANUAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction................Post Setup / Fork Compatibility........Accessories................Frame Features..............Frame Geometry..............Shock Setup................Optional Derailleur Guard Installation......Schematic and Specifications.......... Warranty...................

  • Page 4: Introduction

    INTRODUCTION Congratulations on your purchase and welcome to the finest line of suspension bikes available! About Off Road, Stunt, Downhill and Freeriding This manual is designed to be used in conjunction with the Bicycle Owner’s Manual and owner’s manuals supplied by the manufacturer of the front and rear suspension components.
  • Page 5 INTRODUCTION Here is what you should look for when you inspect your bicycle for this type of riding: bent or broken components, such as the handlebar, handlebar stem, seatpost, pedals; dents, cracks, scratches, deformation, or discoloration. Because damage may be internal and hidden, if any of these signs are present, stop riding until your bicycle has been thoroughly inspected by your Specialized dealer.
  • Page 6 INTRODUCTION Service and Modifications Technological advances have made bicycles and bicycle components more complex, and the pace of innovation is increasing. It is impossible for this manual or the accompanying manuals to provide all of the information required to properly repair and/or maintain your bicycle.

  • Page 7: Post Setup / Fork Compatibility

    FORK SETUP INFORMATION WARNING: The Stumpjumper 120 frame is compatible ONLY with single crown forks that have travel of 5.1” (130mm) or less. Use of different styled forks or forks with longer travel may result in catastrophic failure of the frame which may result in serious personal injury or death.

  • Page 8: Accessories

    MUDFLAP FENDER CHAINSTAY SLEEVE The Stumpjumper Mudflap is compatible with all Replacement custom neoprene chainstay 04-06 Stumpjumper FSR and 05-06 FSRxc models, SlapJacket sleeves are available through your local available through your local Specialized dealer. Specialized dealer. SJ MudFlap Part #:...

  • Page 9: Frame Features

    STUMPJUMPER 120 FRAME FEATURES 1. Main Frame 2. Seatstay 3. Chainstay 4. Shock Link 5. Main Pivot 6. Dropout (Horst) Pivot 7. Shock Link at Seatstay Pivot 8. Shock Link at Frame Pivot 9. Lower Shock Eyelet 10. Upper Shock Eyelet 11.

  • Page 10: Frame Geometry

    STUMPJUMPER 120 FRAME GEOMETRY Stumpjumper FSR 120 Men’s Small Men’s Medium Men’s Large Men’s X-Large *Top Tube Length 551mm (21.70“) 587mm (23.10”) 612mm (24.10”) 638m (25.12”) **Standover Hgt 723mm (28.46”) 729mm (28.70”) 732mm (28.82”) 739mm (29.09”) Head Tube Length 100mm (3.94”)
  • Page 11 STUMPJUMPER 120 FRAME GEOMETRY...

  • Page 12: Shock Setup

    200-210 91-95 205-215 Fox Stumpjumper FSR Brain Fade ride tips: Stumpjumper Brain Fade controls the Trail Tune 210-220 95-100 215-225 inertia valve damping. The blue knob adjusts Trail Tune damping from firm (clockwise) to soft...

  • Page 13: Optional Derailleur Guard Installation

    DERAILLEUR GUARD INSTALLATION The Specialized Derailleur guard is available separately through your local Specialized dealer. The guard works with solid or Q/R axle types and is compatible with all Mountain bike models using the 2005-2006 Enduro/Demo derailleur hanger. Guard Part #: 9896-4030 Hanger Part #: 9895-4021 Guard Q/R Axle...
  • Page 15 NOTE: Bearing and Bolt Kits are available only through your local Specialized dealer. To retain your warranty and for your safety, all maintenance should be performed by your local Specialized dealer. Bearing Kit Parts Part # Qty. Part Description Part Specification 1 .

  • Page 16: Warranty

    SBC LIMITED WARRANTY Specialized Bicycle Components, Inc. (“Specialized”), a California corporation located at 15130 Concord Circle, Morgan Hill, California 95037, makes the following Limited Warranty concerning Specialized bicycles and framesets: LIMITED LIFETIME WARRANTY ON BICYCLE FRAMES AND FRAMESETS Subject to the following limitations, terms and conditions, Specialized warrants to the original owner for the lifetime of the original owner of each new Specialized bicycle or frameset that the bicycle frame or frameset when new is free of defective materials and workmanship.
  • Page 17 Baldy; Mondo; Mountain Cage; Mouthport; Nimbus; P.1; P.2;, P.3; P.Brain; P. Street; Pave; Prybaby; Rib Cage; Rockhopper; Roll Model; Roll X; Roubaix, the Stylized “S” logo; S- Works; S1; Sawpit; Sequoia; Shocksox; Sirrus; Spanky; Speed Zone; Streetboy; Strongarm; Stumpjumper; SubZero; Survival Kit; Tarmac; Team Control; Team Master; Team Turbo;...
  • Page 18 15130 Concord Circle Morgan Hill, CA 95037 www.specialized.com © 2006 Specialized Bicycles PN# W2060007...
