SOLTEK 86SP3 Manual page 7

86SP3 / 86SP3-L
1-2 Mainboard Specification Table
86SP3/86SP3-L Specifications and Features
CPU
North Bridge
South Bridge
BIOS
Memory
I/O Chip
AGP interface
Audio
IDE Interface
PCI Slots
I/O Connectors
Networking
Other optional
feature
Models
Optional
Features
LAN Controller
on board
* Note: FSB 800MHz is supported by North Bridge Overclocking.
Socket 478B for P4 CPU( HT CPU included)
Intel 865P, supporting *800/533/400MHz FSB
Intel ICH4
AMI BIOS
Supporting Dual-channel DDR 333/266 SDRAM,
up to 2GB in 2 DIMM slots
IT8712F, with Hardware Monitor
AGP8X/4X Mode only; 1 AGP Slot on board
AC'97 Audio 2.2 compliant, 6 channel audio
2 UATA 66/100 IDE ports
5 PCI Master slots on board
6 USB V2.0, 1 FDD port, 2 COM ports, 1 LPT,
1 IrDA, 1 PS/2 K/B, 1 PS/2 Mouse
LAN Controller RTL8101L and Connector RJ45
(for 86SP3-L only)
PS/2 Keyboard/Mouse Wake Up
86SP3
No
10
86SP3-L
Yes
