1. Parts included in the package
Cup mounting flange 1 pc.
Parallel pin (6x10): 1 pc.
Hexagon socket head cap
screw (M6x10): 4 pcs.
Suction cup with adapter: 4 pcs.
Plug: 1 pc.
Plug: 4 pcs.
Part No. M-5P
Part No. M-3P
When Rc1/8 port use as vacuum pressure supply port.
Used for decreasing the number of
(Mount to unused port.)
suction cups.
-4-
No. TQ1230001-OM107
