Eden 11530-EDAMZ Instructions

41.5"
(105cm)
27.5"
(70cm)
MULTI-PATTERN SPRINKLER PLUS MISTING SYSTEM
Step 1
Place the tripod in the area
where you want to water.
Push down on the tripod legs
until the spikes are well
seated in the ground.
(Follow the waring yellow
sign on the tripod to avoid
crimping your thumb)
Step 2
Attach your watering hose
connector to the base of
the tripod. Tighten the
hose connector until rmly
connected.
(For setup, you can choose
Type A or Type B)
Step 3
Simply attach the gear
driver to the top of the
Tripod.
Spray Coverage and
Distance Adjustment
Adjust the range tabs and angle cap to change
the spray coverage(from 5°up to 360°) and
spraying angle according to your need.
Spray Pattern Adjustments
Depending on your watering needs, you can manually select from the
various pattern settings :
FLAT - The at pattern will provide a at wave of water.
FAN - The fan pattern disperses water in a wide fan sharpe.
MIST - This pattern is useful to cool down a small area.
LARGE - This provides a larger watering spray area.
MULTI - This is a combination of the Flat, Fan and Large patterns.
Type A
LOCK
11530-EDAMZ
WATER
Type B
