Data structure:
Offset Field Name
0 Response to
Challenge 1
8 Session ID
Result codes:
Example Activation Challenge Reply Request (Hex):
Cmd Num
11
Example Activation Challenge Reply Response (Hex):
Result Code
00

Deactivate Authenticated Mode Command

Command number:
Description:
If the reader decrypts the CR response correctly the Activate
Authenticated Mode has succeeded. If the reader can not decrypt the CR
command correctly the Activate Authenticated Mode has failed, the
DUKPT KSN advances.
Request Data:
Description
Six bytes of Challenge 1 plus two bytes of time as
outlined above, encrypted by the specified variant of
the current DUKPT Key
Optional eight byte Session ID encrypted by the
specified variant of the current DUKPT Key.
Response Data: None
0x00 Success
0x02 Bad Parameters – the Request Data is not a correct length
0x04 Bad Data – the encrypted reply data could not be verified
0x07 Sequence – not expecting this command
Data Len
08
Data Len
00
0x12
This command is used to exit the Authenticated Mode command. It can
be used to exit the mode with or without incrementing the DUKPT
transaction counter (lower 21 bits of the KSN). The application must send
the first 7 bytes of Challenge 2 (from the response to the Activate
Authenticated Mode command) and the Increment flag (0x00 indicates no
increment, 0x01 indicates increment of the KSN) encrypted with a variant
of the current DUKPT PIN Encryption Key (Key XOR 3C3C 3C3C 3C3C
3C3C 3C3C 3C3C 3C3C 3C3C).
If the reader decrypts Challenge 2 successfully it will exit the
Authenticated Mode and, depending on the Increment flag, may increment
the KSN.
If the reader cannot decrypt Challenge 2 successfully, it will stay in the
Authenticated Mode until either the time specified in the Activate
Authenticated Mode command passes or the user swipes a card. This
Section 2. Communications
Data
8579827521573495
Data
67
