361TS
Non-Tub Spout
Operation & Maintenance Manual
Model Numbers
☐
361TS
Non-Diverter Tub Spout
Options/Modifications
☐
-STN
Satin Nickel finish
Note: Append appropriate -suffix to model number.
Dimensions
A
D
Note: Dimensions subject to change without notice.
Duro
®
Specification
•
6" length
•
Thread on installation
•
Metal construction plated in standard polished chrome
finish
Compliance
-ASME A112.18.1/CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
B
E
Measurements
A
2-1/4", 57 mm
B
3/8", 10 mm
Female 1/2-14 NPT fitting must
C
be recessed 3/8" (10 mm)
from finished wall
D
2-3/4", 70 mm
E
6", 152 mm
C
