352TS
Dia
Diverter Tub Spout
™
Operation & Maintenance Manual
Model Number
352TS
Modifications
-STN
Satin nickel finish
Note: Append appropriate -suffix to model number.
Dimensions
A A
Note: Dimensions are subject to change without notice.
Symmons Industries, Inc.
1
©2014 Symmons Industries, Inc.
Dia Diverter Tub Spout
B B
C C
■
31 Brooks Drive
■
www.symmons.com
Specifications
7" diverter tub spout made from metal and plastic
materials plated in standard polished chrome finish.
Compliance
-ASME A112.18.1/CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
A
B
C
D
Required for Installation
Teflon Tape
D D
■
■
Braintree, MA 02184
(800)796-6667
■
gethelp@symmons.com
Measurements
Ø 2 1/2", 64 mm
4 3/4", 121 mm
7", 178 mm
1/2"-14 NPT
■
Fax: (800)961-9621
■
ZV-3014 REV 0 01/15/2014
