  • Page 1 SuperBlade Server SBI-420P-1C2N SBI-420P-1T3N USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wftp/utility/...

  • Page 4: Table Of Contents

    SuperServer SBI-420P-1(C2/T3)N User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................7 Eligible Enclosures ......................7 1.2 System Features ........................8 1.3 Front View ..........................9 Control Panel ........................10 1.4 Components ........................11 Chapter 2 Installation and Setup 2.1 Unpacking the System .......................13 2.2 Installing or Removing the Blade Unit ................14 Installing a Blade Unit into the Enclosure .................14 Removing a Blade Unit from the Enclosure ..............14 Removing and Replacing the Blade Cover ...............15...
  • Page 5 Contents Checking the Temperature of an NVMe Drive ..............36 M.2 Solid State Drives .....................37 2.7 Installing the Operating System ..................38 Linux Installation with Two Storage Drives ...............39 2.8 Configuring and Setting up RAID ..................39 2.9 Driver Installation ........................40 Chapter 3 Management and Maintenance 3.1 Management Software ......................41 IPMI ...........................41 BMC ADMIN User Password ..................41...
  • Page 6 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 7: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction 1.1 Overview The SBI-420P-1(C2/T3)N blade is a compact self-contained server that connects into a pre- cabled enclosure that provides power, cooling, management and networking functions. One 8U enclosure can hold up to twenty blades. Each blade contains one computing node. In this manual, “blade”...

  • Page 8: System Features

    Motherboard B12DPT-6 Dual Intel Xeon 3rd Gen Scalable processors (in Socket P4 LGA4189) with up to 38 cores and a thermal design power (TDP) of up to 270W; for the updates, refer to our website at Supermicro.com Chipset Intel C621A...

  • Page 9: Front View

    Chapter 1: Introduction 1.3 Front View The illustration below shows the features on the front of the blade unit. Figure 1-1. Front View, SBI-420P-1T3N Chassis Front Features Item Features Description Control Panel Power button and status indicators Two hot-swap 2.5" drive bays for NVME, SAS, or SATA; the drive carriers display Storage Drives status lights Storage Drive...

  • Page 10: Control Panel

    Super Blade SBI-420P-1(C2/T3)N User's Manual Control Panel Power switches and status LEDs are located on the control panel on the front of the chassis. Figure 1-3. Control Panel Control Panel Features Item Feature State Description The main power switch applies or removes primary power from the Power button power supply to the server but maintains standby power.

  • Page 11: Components

    Chapter 1: Introduction 1.4 Components SBI-420P-1C2N SBI-420P-1T3N Figure 1-4. Components Labeled (see next page)
  • Page 12 Super Blade SBI-420P-1(C2/T3)N User's Manual Blade Components Item Feature Description Drive SBI-420P-1T3N only; 2.5" SATA storage drive Processor and heatsink Memory DIMM slots Air Shrouds Direct air flow Module SBI-420P-1C2N only; enables Broadcom 3108 RAID controller Module SBI-420P-1T3N only; provides SATA for third drive Chipset Motherboard chipset Add-on card provides one of: EDR, HDR, M.2 storage, Omnipath 100Gbps, or...

  • Page 13: Chapter 2 Installation And Setup

    This chapter provides instructions on installing and replacing user-replaceable components. To prevent compatibility issues, use only components that match the specifications or parts qualified by Supermicro. Up to twenty blade modules may be installed into a blade enclosure. Blade modules with different operating systems, such as Windows and Linux, may be mixed together in the same blade enclosure.

  • Page 14: Installing Or Removing The Blade Unit

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual 2.2 Installing or Removing the Blade Unit Installing a Blade Unit into the Enclosure Make sure the cover of the blade unit is on before insertion. Installing a Blade Unit into the Enclosure 1. Pull open the blade locking handle and slowly push the blade into its bay. 2.

  • Page 15: Removing And Replacing The Blade Cover

    Chapter 2 Installation and Setup Removing and Replacing the Blade Cover The blade cover can be removed to access the mainboard and install processors, memory modules, the onboard battery, etc. • To remove the cover, remove the screw as illustrated below. Slide the cover toward the rear and lift it off.

  • Page 16: Powering Up Or Down

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual 2.3 Powering Up or Down Each blade unit may be powered on and off independently from the rest of the blades in the enclosure. Powering Up a Blade Unit A blade unit may be powered up in two ways: •...

  • Page 17: Processor And Heatsink Installation

    • Thermal grease is pre-applied on new heatsinks. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • Graphics in this manual are for illustration only. Your components may look different.

  • Page 18: The Processor Carrier Assembly

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual The Processor Carrier Assembly The processor carrier assembly is comprised of the processor and the processor carrier. 1. Hold the processor with the land grid array (LGA, gold contacts) facing down. Locate the gold triangle at the corner of the processor and the corresponding hollowed triangle on the processor carrier as shown below.
  • Page 19 Chapter 2 Installation and Setup 3. Locate the lever on the carrier and, if necessary, press it down as shown below. Lever 4. Align the CPU keys on the processor (A & B) with those on the carrier (a & b) as shown below.

  • Page 20: The Processor Heatsink Module (Phm)

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual The Processor Heatsink Module (PHM) After creating the processor carrier assembly, mount the heatsink onto the carrier assembly to form the processor heatsink module (PHM). Note: If this is a new heatsink, the thermal grease has been pre-applied. Otherwise, apply the proper amount of thermal grease to the underside of the heatsink.

  • Page 21: Installing The Phm Into The Cpu Socket

    Chapter 2 Installation and Setup Installing the PHM into the CPU Socket 1. Remove the plastic protective cover from the CPU socket. Gently squeeze the grip tabs then pull the cover off. CPU Socket with Plastic Protective Cover Grip Tabs...
  • Page 22 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual 2. Locate four threaded fasteners (a, b, c, d) on the CPU socket. CPU Socket Threaded Fastener (a, b, c, d: Threaded Fasteners) CPU Socket Pin1 3. Locate four PEEK nuts (A, B, C, D) and four rotating wires (1, 2, 3, 4) on the heatsink as shown below.
  • Page 23 Chapter 2 Installation and Setup 5. Align nut A (next to the triangles and pin 1) on the heatsink with threaded fastener "a" on the CPU socket. Also align nuts B, C, D on the heatsink with threaded fasteners b, c, d on the CPU socket.

  • Page 24: Removing The Phm From The Cpu Socket

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Removing the PHM from the CPU Socket Be sure the system is shut down and all AC power cords are unplugged. 1. Use a t30-bit screwdriver to loosen the four PEEK nuts on the heatsink in the sequence of A, B, C, and D.

  • Page 25: Removing The Processor Carrier Assembly From The Phm

    Chapter 2 Installation and Setup Removing the Processor Carrier Assembly from the PHM Detach the four plastic clips (a, b, c, d) on the processor carrier assembly from the four corners of the heatsink (A, B, C, D) as shown below, and lift off the processor carrier assembly. Processor Carrier Assembly Pin 1 Pin 1...

  • Page 26: Removing The Processor From The Carrier Assembly

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Removing the Processor from the Carrier Assembly Unlock the lever from its locked position and push it upwards to disengage the processor from the carrier as shown below right. Carefully remove the processor from the carrier. Processor Carrier Assembly Lever Note: Handle the processor with care to avoid damage.

  • Page 27: Memory

    Chapter 2 Installation and Setup 2.5 Memory Memory Support The B12DPT-6 has 16 DIMM slots for up to 2TB of 3DS LRDIMM/LRDIMM/3DS RDIMM/ RDIMM DDR4 (288-pin) ECC memory with speeds of 3200/2933/2666MT/s. For validated memory, use our Product Resources page. DDR4 Memory Support for 83xx/63xx/53xx/43xx Processors Speed (MT/s)

  • Page 28: Memory Population Guidelines

    Blue slots versus black slots: Install the first DIMM in the blue memory slot, which is the first of a memory channel. The following memory population sequence table was created based on guidelines provided by Intel to support Supermicro motherboards.
  • Page 29 Chapter 2 Installation and Setup Memory Population for the X12 DP Motherboard, 16 DIMM Slots CPUs/DIMMs Memory Population Sequence 1 CPU & 1 DIMM 1 CPU & 2 DIMMs A1, E1 1 CPU & 3 DIMMs* A1, C1, E1 1 CPU & 4 DIMMs A1, C1, E1, G1 1 CPU &...

  • Page 30: Installing Memory

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge. •...

  • Page 31: Storage Drives

    The blade can be purchased with drives installed or without drives installed. For VROC configurations, refer to the VROC appendix in this manual. Note: Enterprise level storage drives are recommended for use in Supermicro systems. For information on recommended drives, visit the Supermicro website.
  • Page 32 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Removing a Hot-Swap Drive Carrier from the Chassis 1. Press the release button (shown below as ) on the drive carrier, which will extend the drive carrier handle. 2. Use the drive carrier handle to pull the drive out of the chassis. Figure 2-4.
  • Page 33 Chapter 2 Installation and Setup Installing a Drive 1. Remove the dummy drive, which comes pre-installed in the drive carrier. Pull out the two locking clasps on the left outside of the carrier and lift out the dummy drive. 2. Position the drive above the carrier with the PCB side facing down and the connector end toward the rear of the carrier.

  • Page 34: Hot-Swap For Nvme Drives

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Hot-Swap for NVMe Drives Supermicro servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using IPMI. Note: If you are using VROC, see the VROC appendix in this manual instead.

  • Page 35: Checking The Temperature Of An Nvme Drive

    Chapter 2 Installation and Setup Checking the Temperature of an NVMe Drive There are two ways to check using IPMI. Checking a Drive • IPMI > Server Health > NVMe SSD – Shows the temperatures of all NVMe drives, as in Figure 2-6.

  • Page 36: Solid State Drives

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual M.2 Solid State Drives One option for the mezzanine card supports M.2 solid state drives (SSDs) of 80mm in length. There is an hole in the motherboard standoff for a plastic clasp. Installing an M.2 SSD Caution: Use industry-standard anti-static equipment, such as gloves or wrist strap, and follow precautions to avoid damage caused by ESD.

  • Page 37: Installing The Operating System

    Windows OS and blades with Linux OS can both occupy and operate within the same blade enclosure. Refer to the SuperMicro web site for a complete list of supported operating systems. There are several methods of installing an OS to the blade modules.

  • Page 38: Linux Installation With Two Storage Drives

    SDA. If the SATA controller mode operation is changed to AMD_AHCI in the BIOS, then the HDDs will appear as SDA and SDB. 2.8 Configuring and Setting up RAID For RAID setup, see http://www.supermicro.com/support/manuals/ under RAID Installation Guides.

  • Page 39: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or a DVD.

  • Page 40: Chapter 3 Management And Maintenance

    BIOS settings that are related to IPMI. For general documentation and information on IPMI, visit our website at: http://www.supermicro.com/products/nfo/IPMI.cfm. BMC ADMIN User Password For security, each system is assigned a unique default BMC password for the ADMIN user.

  • Page 41: Motherboard Battery

    Chapter 3 Management and Maintenance 3.2 Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 42: System Cooling

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual 3.3 System Cooling Installing the Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. Installing the Standard Air Shrouds • Position the air shrouds as illustrated in the figure below, sliding them over the components, and secure them with screws.

  • Page 43: Checking The Server Air Flow

    • Do not operate the server without drive carriers in the drive bays. • Use only Supermicro recommended server parts. • Make sure no wires or foreign objects obstruct air flow through the chassis. Pull all excess cabling out of the airflow path or use shorter cables.

  • Page 44: Where To Get Replacement Components

    (http://www.supermicro.com/ support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping.

  • Page 45: Chapter 4 Motherboard Connections

    Chapter 4 Motherboard Connections Chapter 4 Motherboard Connections This chapter describes the jumpers, connections and LEDs on the motherboard and provides pinout definitions. Some connections might not be used in this system. 4.1 Motherboard Layout Below is a layout of the B12DPT-6 with descriptions on the following page. 25G Midplane MB PWR LEDM1...
  • Page 46 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Quick Reference Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) JPME1 ME Manufacturing Recovery Pins 1-2 (Normal) Connector Description Onboard CMOS battery CPLD0 Complex Programmable Logic Device (CPLD) chip FAN1 Cooling fan header reserved for liquid cooling HDD0/HDD1 Front accessible Hard Driver Connector #0/Hard Driver Connector #1 HDD2_PWR...

  • Page 47: Chipset Block Diagram

    USB2_7 USB2_2 ESPI TMP432 RT1/RT2/RT8 CPLD JUSB0 FLASH CPLD USB3.0 Type A (PFR) BMC Boot Flash DUAL Supermicro BOOT Debug only TPM HEADER BIOS Debug Card JFP1 VGA/COM1/Temperature Sensor VGA/ USBx2/ COM1 To KVM connector Figure 1-7. Chipset Block Diagram...

  • Page 48: Power Connections

    The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from Supermicro. A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the storage drive is not installed in the system.
  • Page 49 Chapter 4 Motherboard Connections RAID Key Header A VROC RAID Key header is located at JRK1. It supports VMD used in creating optional advanced NVMe RAID configurations. See the VROC appendix for details. RAID Key Header Pin Definitions Pin# Definition Ground 3.3V Standby Ground...

  • Page 50: Jumpers

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.

  • Page 51: Led Indicators

    Chapter 4 Motherboard Connections 4.5 LED Indicators BMC Heartbeat LED LEDM1 is a BMC Heartbeat indicator. It blinks green when the BMC is working properly. M.2 Activity LED LED1 is an M.2 Activity indicator. When it is blinking green, M.2 is active.

  • Page 52: Chapter 5 Uefi Bios

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Chapter 5 UEFI BIOS 5.1 Introduction This chapter describes the AMI UEFI BIOS setup utility for the B12DPT-6 and provides the instructions on navigating the setup screens. The BIOS is stored in a Flash EEPROM and can be updated.
  • Page 53 HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2016 after RTC reset. Supermicro B12DPT-6 (Motherboard model) BIOS Version Build Date (of the BIOS)

  • Page 54: Tab

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual 5.3 Tab Pages Advanced Boot Function CPU Configuration Chipset Configuration SATA Configuration sSATA Configuration PCIe/PCI/PnP Configuration Super IO Configuration Serial Port Console Redirection ACPI Settings Trusted Computing SIO Common Settings T1s Auth Configuration All Cpu Information RAM Disk Configuration iSCSI Configuration IPv4 Network Configuration...
  • Page 55 Chapter 5 UEFI BIOS Boot Boot Mode Select Delete Boot Option Delete Driver Optioni UEFI Application Boot Priorities UEFI NETWORK Drive BBS Priorityies Save & Exit Save Options Default Options Boot Override...

  • Page 56: Appendix A Bios Post Codes

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Appendix A BIOS POST Codes A.1 BIOS POST Messages During the Power-On Self-Test (POST), the BIOS will check for problems. If a problem is found, the BIOS will activate an alarm or display a message. The following is a list of such BIOS messages.
  • Page 57 Appendix A BIOS POST Codes BIOS POST Messages BIOS Message Description Previous POST did not complete successfully. POST loads default values and offers to run Setup. If the failure was caused by incorrect values and Previous boot incomplete - they are not corrected, the next boot will likely fail. On systems with control of Default configuration used wait states, improper Setup settings can also terminate POST and cause this error on the next boot.
  • Page 58 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual BIOS POST Messages BIOS Message Description nnnn kB Extended RAM Where nnnn is the amount of RAM in kilobytes successfully tested. Passed nnnn Cache SRAM Passed Where nnnn is the amount of system cache in kilobytes successfully tested. nnnn kB Shadow RAM Passed Where nnnn is the amount of shadow RAM in kilobytes successfully tested.
  • Page 59 Appendix A BIOS POST Codes One long and two short beeps – video configuration error One repetitive long beep – no memory detected Terminal POST Errors If a terminal type of error occurs, BIOS will shut down the system. Before doing so, BIOS will write the error to port 80h, attempt to initialize video and write the error in the top left corner of the screen.
  • Page 60 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Terminal POST Errors Code Description 1-3-1-1 Test DRAM refresh 1-3-1-3 Test 8742 Keyboard Controller Auto size DRAM Initialize POST Memory Manager Clear 512 kB base RAM 1-3-4-1 RAM failure on address line xxxx* 1-3-4-3 RAM failure on data bits xxxx* of low byte of memory bus Enable cache before system BIOS shadow Test CPU bus-clock frequency Initialize Phoenix Dispatch Manager...
  • Page 61 Appendix A BIOS POST Codes Terminal POST Errors Code Description Test keyboard Set key click if enabled Enable USB devices 2-2-3-1 Test for unexpected interrupts Initialize POST display service Display prompt “Press F2 to enter SETUP” Disable CPU cache Test RAM between 512 and 640 kB Test extended memory Test extended memory address lines Jump to UserPatch1...
  • Page 62 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Terminal POST Errors Code Description Detect and install external parallel ports Initialize PC-compatible PnP ISA devices Re-initialize onboard I/O ports. Configure Motherboard Configurable Devices (optional) Initialize BIOS Data Area Enable Non-Maskable Interrupts (NMIs) Initialize Extended BIOS Data Area Test and initialize PS/2 mouse Initialize floppy controller Determine number of ATA drives (optional)
  • Page 63 Appendix A BIOS POST Codes Terminal POST Errors Code Description Clear Boot flag Check for errors Inform RomPilot about the end of POST. POST done - prepare to boot operating system 1 One short beep before boot Terminate QuietBoot (optional) Check password (optional) Initialize ACPI BIOS Prepare Boot...
  • Page 64 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Terminal POST Errors Code Description Initialize digitizer and display message Unknown interrupt The following are for the boot block in Flash ROM: Boot Block Flash ROM Terminal POST Errors Code Description Initialize the chipset Initialize the bridge Initialize the CPU Initialize system timer Initialize system I/O...
  • Page 65 Appendix A BIOS POST Codes Boot Block Flash ROM Terminal POST Errors Code Description Initialize interrupt vectors Initialize Run Time Clock Initialize video Initialize System Management Manager Output one beep Clear Huge Segment Boot to Mini DOS Boot to Full DOS If the BIOS detects error 2C, 2E, or 30 (base 512K RAM error), it displays an additional word- bitmap (xxxx) indicating the address line or bits that failed.

  • Page 66: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 67 Appendix B Standardized Warning Statements for AC Systems Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 68 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 69 Appendix B Standardized Warning Statements for AC Systems Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 70 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 71 Appendix B Standardized Warning Statements for AC Systems Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 72 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 73 Appendix B Standardized Warning Statements for AC Systems ¡Advertencia! Solamente el personal calificado debe instalar, reemplazar o utilizar este equipo. Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬...
  • Page 74 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 75 Appendix B Standardized Warning Statements for AC Systems Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 76 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 77 Appendix B Standardized Warning Statements for AC Systems ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 78 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 79 Appendix B Standardized Warning Statements for AC Systems ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스...
  • Page 80 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 81 Appendix B Standardized Warning Statements for AC Systems Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 82 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 83 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 84 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 85 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 86: Appendix C Cpu-Based Raid For Nvme

    SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Appendix C CPU-Based RAID for NVMe Intel Virtual RAID on CPU (Intel VROC) is an enterprise RAID solution for NVMe SSDs ® directly attached to Intel Xeon Scalable processors. Intel Volume Management Device (VMD) is an integrated controller inside the CPU PCIe root complex. •...
  • Page 87 Appendix C CPU-Based RAID for NVMe Additional Information Additional information is available on the product page for the Supermicro add-on card and the linked manuals. www.supermicro.com/products/accessories/addon/AOC-VROCxxxMOD.cfm www.supermicro.com/manuals/other/AOC-VROCxxxMOD_Windows.pdf C.1 Hardware Key The Intel VROC hardware key is a license key that detects the Intel VROC SKU and activates the function accordingly.
  • Page 88 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual C.2 Enabling NVMe RAID RAID for NVMe SSDs must be enabled through the UEFI BIOS. 1. Install the patch as described in the Restrictions and Requirements section on a previous page. 2. Reboot the server and press [DEL] key to enter BIOS. 3.
  • Page 89 Appendix C CPU-Based RAID for NVMe 5. Select the desired PStack# to Enable or Disable the corresponding Intel VMD controller Figure C-3. BIOS, Enabling VMD for Pstack0 6. Select the desired PCIe slot to Enable or Disable Intel VMD functionality according to the current hardware configuration being used.
  • Page 90 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual 7. Repeat steps 5-6 for each PStack# on each CPU to be enabled or disabled. In this example, we enabled CPU1 Slot1 (Figure C-5) and CPU2 Slot5 (Figure C-6) (our 4x U.2 form factor SSDs), as well as CPU1 M.2 C-1 and CPU1 M2. C-2 (our 2x M.2 form factor SSDs).
  • Page 91 Appendix C CPU-Based RAID for NVMe 8. Press [F4] to save the configuration and reboot the system and press [DEL] to enter BIOS. Note: Disabling the VMD controller without first deleting the associated existing RAID volume can lead to unexpected behavior. This action is strongly not recommended. Note: The effects of physically changing or swapping a CPU on the VMD controller enablement has not yet been thoroughly tested or documented.
  • Page 92 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual C.3 Status Indications An LED indicator on the drive carrier shows the RAID status of the drive. Drive Carrier Status LED Indicator Status State (red) Normal function Locating 4 Hz blink Fault Solid on Rebuilding 1 Hz Blink IBPI SFF 8489 Defined Status LED States C.4 Hot Swap Drives...
  • Page 93 Appendix D: System Specifications Appendix D Specifications and Compliance Processors with up to 38 cores and a thermal design power (TDP) of Intel Xeon 3rd Gen Scalable in a P4 LGA4189 type socket, up to 270W Chipset Intel C621A Memory Sixteen slots for up to 2TB of 3DS LRDIMM/LRDIMM/3DS RDIMM/RDIMM/ DDR4 ECC memory with speeds of 3200/2933/2666MHz;...
  • Page 94 SuperBlade Server SBI-420P-1(C2/T3)N User's Manual Regulatory Compliance FCC, ICES, CE, VCCI, RCM, NRTL, CB Applied Directives, Standards EMC/EMI: 2014/30/EU (EMC Directive) FCC Part 15 ICES-003 VCCI 32-1 AS/NZS CISPR 32 EN55032 EN55035 CISPR 24 EN 61000-3-2 EN 61000-3-3 EN 61000-4-2 EN 61000-4-3 EN 61000-4-4 EN 61000-4-5...

This manual is also suitable for:
