Parker IQAN-MC3 Installation

Mounting dimensions

1 6
A 7 12
13 18
1 6
B 7 12
13 18
1 6
C
7 12
13 18
1 6
D
7 12
13 18
210
230
76
55
Ø 6.5
M6 screw (2x)
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS AND/OR
SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL
INJURY AND PROPERTY DAMAGE.
This document and other information from Parker Hannifin Corporation, its subsidiaries and authorized distributors provide
product and/or system options for further investigation by users having technical expertise. It is important that you analyze
all aspects of your application, including consequences of any failure, and review the information concerning the product or
Ø6.5 (2x)
system in the current product catalogue. Due to the variety of operating conditions and applications for these products or
systems, the user, through its own analysis and testing, is solely responsible for making the final selection of the products
and systems and assuring that all performance, safety and warning requirements of the application are met.
The products described herein, including without limitation, product features, specifications, designs, availability and pricing,
are subject to change by Parker Hannifin Corporation and its subsidiaries at any time without notice.
For further information see:
HY33-8001-IB/UK Instruction book IQAN-MC3
HY33-8001-DC/UK Declaration of conformity IQAN-MC3
units = mm
IQAN-MC3
NOTICE
Connectors must be properly installed
to meet environmental specification.
• Sealing plugs must be inserted in
all unused pin positions.
• All connectors must be installed.
WARNING
Installation IQAN-MC3
Publ.no: HY33-8001-IS/UK
Ed. 01/2013
IQAN master or
expansion unit
125
100
80
60
40
-40 - +85°C
20
0
-20
-40
(2004/108/EC)
(2006/42/EC)
Eng.no: M5010065A
Rev. C
