Parker ETH080 Mounting Instructions

High force electro thrust cylinder
Hide thumbs Also See for ETH080:
Table of Contents

Advertisement

Quick Links

Download this manual
ETH -
Electromechanical
Elektrozylinder
Electromechanical Automation
Cylinders
Mounting instructions
ETH Manual - Installation, Commissioning, Maintenance and Repair
ETH - Electro Cylinder
Parker High Force Electro Thrust
Cylinder
192-550002N2.EMN
ETH Mounting instructions
Revision: B
November 21,2018
Technical Changes Reserved
21.11.18 07:42192-550002N2 ETH Mounting instructions March 2011September 2012
Data shown complies with known technical data when printed.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETH080 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Parker ETH080

Summary of Contents for Parker ETH080

  • Page 1 Electromechanical Elektrozylinder Electromechanical Automation Cylinders Mounting instructions ETH Manual - Installation, Commissioning, Maintenance and Repair ETH - Electro Cylinder Parker High Force Electro Thrust Cylinder 192-550002N2.EMN ETH Mounting instructions Revision: B November 21,2018 Technical Changes Reserved 21.11.18 07:42192-550002N2 ETH Mounting instructions March 2011September 2012...
  • Page 2 Fax: (724) 861 - 3330 Internet: www.parkermotion.com E-mail: ddlcat@parker.com Headquarters: Parker Hannifin S.p.A • SSD SBC • Electromechanical Automation • Via Gounod, 1 Italy: I-20092 Cinisello Balsamo (MI), Italy Tel.: +39 (0)2 66012459 • Fax: +39 (0)2 66012808 E-mail: sales.automation@parker.com mailto:sales.sbc@parker.com •...

  • Page 3: Table Of Contents

    Introduction Parker EME/EMN Content Assembly Instructions 1. Introduction........................6 Device assignment .................... 6 Type specification plate ..................6 Mounting explanation ..................7 Safety instructions .................... 8 1.4.1. General hazards ....................8 1.4.2. Intended use ....................... 8 1.4.3. Identifying Residual Dangers and Hazardous Areas ........8 1.4.4.
  • Page 4 ETH- Electromechanical Cylinders Introduction 5. Index ........................... 30 6. Further information ....................31 7. Revisions ........................31 2011 192-550002N2 ETH Mounting instructions March...
  • Page 5 ..................33 Example for Dimensioning with Predefined Drive Trains........33 Predefined Motion Packages for ETH032 ............34 Predefined Motion Packages for ETH050 ............36 Predefined Motion Packages for ETH080 ............38 Order code....................40 2011 192-550002N2 ETH Mounting instructions March...

  • Page 6: Introduction

    Type specification plate Type specification plate (example) Serial number: 285950-0001 Type: ETH050M05A1K1AFMN0200A Order confirmation No.: 21015463 Date: 02.11.2010 Made in Germany Parker Hannifin GmbH Electromechanical Automation Robert-Bosch-Straße 22 D-77656 Offenburg Tel.+49(0)781 509-0 Parker Hannifin EMN 1140 Sandy Hill Rd. Irwin, PA 15642 724-861-8200 800-245–...

  • Page 7: Mounting Explanation

    Introduction Parker EME/ EMN Mounting explanation 2011 192-550002N2 ETH Mounting instructions March...

  • Page 8: Safety Instructions

    Introduction ETH- Electromechanical Cylinders Safety instructions 1.4.1. General hazards General Hazards on Non-Compliance with the Safety Instructions The subsystem has been designed in accordance with state-of-the-art technical developments and is operationally reliable. If it is not operated by qualified, or at least trained personnel, or if it is operated improperly or not in accordance with the operating instructions, the unit may bear the risk of hazards.

  • Page 9: Working Safely

    Introduction Parker EME/ EMN 1.4.4. Working safely Heed the Instructions The information (such as instructions and notes) contained in this manual must be heeded for all work involved in installing, commissioning, setting up, operating, changing operating conditions and modes, servicing, inspecting and repairing the unit.

  • Page 10: Safety Instructions For Operating Personnel

    Components and accessories are designed especially for this product. When purchasing spare and wearing parts, use only original Parker parts. We note here explicitly that we are unable to check or release spare parts or accessories that were not provided by us.

  • Page 11: Special Notes On Transport

    Introduction Parker EME/ EMN 1.5.1. Special notes on transport Special notes on transport Use only transport equipment with sufficient lifting capacity. When using ropes, make certain they are not twisted or knotted. If you are using more than one rope, all the ropes should be equally taut.

  • Page 12: Warranty Conditions

    Introduction ETH- Electromechanical Cylinders Warranty conditions User Conversions and Changes are Not Permitted The linear actuator must not be changed in its design or in terms of safety without our approval. Any change as defined here made by the user excludes any liability on our part. Conditions of utilization General introductory notes With the ETH electro cylinder you bought a product which was manufactured and tested...
  • Page 13 Introduction Parker EME/ EMN If the motor used with the electro cylinder should be able to exceed individual limit values of the cylinder, the respective values for the motor must be limited in the control by appropriate parameterization. The parameterization should even be reduced down to the values necessary for operation.

  • Page 14: Set-Up

    The technical data must be respected. See from page 6 in the catalog section (following the mounting instructions). Mounting Please use only the parts offered in the Parker ETH catalog for the following mounting components: Rear Eye Mounting (order code E) ◆...

  • Page 15: Screw Tightening Torques For The Mounting Of The Eth Cylinder By The Customer

    Set-Up Parker EME/ EMN Screw tightening torques for the mounting of the ETH 2.1.2.1 cylinder by the customer. In order to simplify the calculation of the mounting screws for fixing the cylinder in your application, the following table gives an overview of the required screw quality resp.

  • Page 16: Accessory Mounting - Bearing Block

    Accessory mounting – bearing block 2.1.2.2 When mounting the bearing blocks, customers should respect the following tightening torques. ETH032 ETH050 ETH080 0112.039 0122.039 0132.039 Pa rt number M8 -12.9 M10 - 12.9M12 - 12.9 Screw Screw ti ghteni ng torque (1) [Nm]...

  • Page 17: Electric Installation

    Set-Up Parker EME/ EMN Electric installation 2.2.1. Sensors All electro cylinders feature a permanent magnet in the spindle nut. It activates the limit switches which are mounted in the special mounting grooves on one side of the cylinder. Sensors and limit switches: see from page 28 in the catalog section (following the mounting instructions).

  • Page 18: Setting The End Limits

    Set-Up ETH- Electromechanical Cylinders 2.2.4. Setting the end limits The steps described below can be best executed with energized drive. Therefore, they may only be performed by trained and authorized personnel. Do only travel at very low speed (<10 mm/s) and reduce the drive torque to a minimum.

  • Page 19: Motor And Feedback Mounting

    Set-Up Parker EME/ EMN Motor and feedback mounting In this chapter you can read about: Motor / gearbox mounting with inline motor configuration..........20 Motor / gearbox mounting with parallel motor configuration ..........21 Notes on motor wiring In order to adhere to the EMC directive, it is necessary to mount the motor if ever possible unchanged.

  • Page 20: Motor / Gearbox Mounting With Inline Motor Configuration

    Slip the coupling half onto the motor / gearbox shaft and align to be flush with the ◆ shaft if not stated otherwise by Parker (Pos. 2). *See page 23 for North American coupling spacing. Tighten clamping screw of the coupling half: ◆...

  • Page 21: Motor / Gearbox Mounting With Parallel Motor Configuration

    Set-Up Parker EME/ EMN 2.3.2. Motor / gearbox mounting with parallel motor configuration In this chapter you can read about: Re-apply toothed belt pre-tension (reinsert the same toothed belt) ........22 Resetting the toothed belt pre-tension (new toothed belt) ..........23...

  • Page 22: Re-Apply Toothed Belt Pre-Tension (Reinsert The Same Toothed Belt)

    Fit toothed pulley and set dimension “A”. ◆ Dimension “A” is provided by Parker. If the drive was exchanged, please set the dimension “A” noted before. *See page 24 for North American “A” dimension. Screw in the toothed pulley threaded pins.

  • Page 23: Resetting The Toothed Belt Pre-Tension (New Toothed Belt)

    Set-Up Parker EME/ EMN Resetting the toothed belt pre-tension (new toothed 2.3.2.2 belt) For a new toothed belt, we recommend to re-set the toothed belt pretension: Check if the belt toothing is geared into the upper and lower toothed pulley.

  • Page 24: Exchanging The Toothed Belt

    Align housing (Fig. 1 Pos. 2) with the electro cylinder. ◆ Tighten 4 screws (Fig. 1 Pos. 1) with the given tightening torque. ◆ ETH032 ETH050 ETH080 9 Nm 20 Nm 40 Nm Mounting the motor (see on page 19)Setting the toothed belt pre-tension: ◆...

  • Page 25: North American Inline Coupling Placement Guide

    Maintenance Parker EME/ EMN North American Inline Coupling Placement Guide ETH32 ETH50 ETH80 Motor "A" mm "B" mm Motor "A" mm "B" mm Motor "A" mm "B" mm "L" mm "L" mm "L" mm Option (MTR) (TBL) Option (MTR) (TBL)

  • Page 26: North American Parallel Pulley Placement Guide

    Maintenance ETH- Electromechanical Cylinders North American Parallel Pulley Placement Guide ETH32 ETH50 ETH80 Motor Motor Motor "A" mm "A" mm "A" mm Option Option Option (MTR) 14.5 15.5 18.5 14.5 15.5 18.5 14.5 18.5 14.5 10.5 14.5 18.5 14.5 18.5 14.5 15.5 18.5...

  • Page 27: Maintenance

    Maintenance Parker EME/ EMN 3. Maintenance In this chapter you can read about: Lubricating intervals and amount of lubricant ..............27 Greasing via central lubrication port (standard) ..............27 Relubrication via central lubrication port (option) .............. 28 The ballscrew drive must be relubricated within given intervals.

  • Page 28: Greasing Via Central Lubrication Port (Standard)

    Maintenance ETH- Electromechanical Cylinders Greasing via central lubrication port (standard) Ø10 ½ ∙ L ½ ∙ L Central lubrication (standard) Central lubrication (Option) Make sure that all external stops are removed. ◆ Retreat thrust rod completely so that it touches the rear stop. ◆...

  • Page 29: Repair

    4. Repair In the event of a damage or a mechanical defect, the entire unit must be returned for repair (Parker Hannifin (see on page 2)). The repair must be made by trained Parker personnel. User Conversions and Changes are Not Permitted The linear actuator must not be changed in its design or in terms of safety without our approval.
  • Page 30 Introduction ETH- Electromechanical Cylinders 5. Index Belt / belt tensions - 22 Re-apply toothed belt pre-tension (reinsert the Conditions of utilization - 11 same toothed belt) - 20 Relubrication via central lubrication port (option) - 26 Device assignment - 5 Repair - 27 Direction of the motor during extension of the Resetting the toothed belt pre-tension (new...
  • Page 31 Introduction Parker EME/ EMN 6. Further information Our product on the Internet: http://www.parker-eme.com/eth http://www.parkermotion.com/ 7. Revisions A. April 1, 2014 Update ETH80 KBB callout to be KBC (pages 25 and 26) November 21,2018 Pg 24, belt part numbers updated to correct numbers...
