Emerson Rosemount 3051G Quick Start Manual

Pressure transmitter with 4-20ma hart protocol (revision 5 and 7)
Hide thumbs Also See for Rosemount 3051G:

Advertisement

Quick Links

Download this manual
Quick Start Guide
00825-0100-4057, Rev EA
March 2020
™
Rosemount
3051G Pressure
Transmitter
®
with 4-20mA HART
Protocol (Revision 5
and 7)

Advertisement

loading

Related Manuals for Emerson Rosemount 3051G

Summary of Contents for Emerson Rosemount 3051G

  • Page 1 Quick Start Guide 00825-0100-4057, Rev EA March 2020 ™ Rosemount 3051G Pressure Transmitter ® with 4-20mA HART Protocol (Revision 5 and 7)
  • Page 2 Explosion-Proof, Flameproof, or intrinsically safe (I.S.) installations. Refer to the Rosemount 3051 Reference Manual (document number 00809-0100-5007) for more instruction. This manual is also available electronically on www.emerson.com. WARNING Explosions could result in death or serious injury.
  • Page 3 March 2020 Quick Start Guide Declaration of Conformity......................28 China RoHS table........................32 Quick Start Guide...
  • Page 4 Quick Start Guide March 2020 Emerson.com/Rosemount...

  • Page 5: System Readiness

    Verify the latest device driver (DD/DTM ) is loaded on your systems to ensure proper communications. • Download the latest device driver at Emerson.com FieldComm Group 1.2.1 Rosemount 3051 device revisions and drivers Table 1-1 provides the information necessary to verify the correct device driver and documentation for your device.

  • Page 6: Transmitter Installation

    3. Mount the transmitter so that the drain/vent valves are oriented upward. Figure 2-1: In-Line Liquid Applications 2.1.2 Gas applications Procedure 1. Place taps in the top or side of the line. 2. Mount beside or above the taps. Emerson.com/Rosemount...
  • Page 7 March 2020 Quick Start Guide Figure 2-2: In-Line Gas Applications 2.1.3 Steam applications Procedure 1. Place taps to the side of the line. 2. Mount beside or below the taps. 3. Fill impulse lines with water. Figure 2-3: In-Line Steam Applications Quick Start Guide...
  • Page 8 Quick Start Guide March 2020 Figure 2-4: Panel and Pipe Mounting Rosemount 3051G Panel mount Pipe mount 1.5 / 16 × 1 ½ Panel bolts are customer supplied. Inline gage transmitter orientation The low side pressure port (atmospheric reference) on the inline gage transmitter is located in the neck of the transmitter, behind the housing.
  • Page 9 March 2020 Quick Start Guide Step 2: Set the switches Set Alarm and Security switch configuration before installation as shown in Figure 2-6. • The Alarm switch sets the analog output alarm to high or low. — Default alarm is high. •...
  • Page 10 2. Connect the positive lead to the “+” terminal (PWR/COMM) and the negative lead to the “–” terminal. 3. Ground housing to fulfill local grounding regulations. 4. Ensure proper grounding. It is important that the instrument cable shield be: Emerson.com/Rosemount...
  • Page 11 March 2020 Quick Start Guide • Trimmed close and insulated from touching the transmitter housing • Connected to the next shield if cable is routed through a junction • Connected to a good earth ground at the power supply end 5.
  • Page 12 A Rosemount 3051 DD must be installed on the Field Communicator to verify configuration. Fast Key sequences for the latest DD are shown in Table 2-1. For Fast Key sequences using legacy DD's, contact your local Emerson representative. Note Emerson recommends installing the latest DD to access the complete functionality.
  • Page 13 March 2020 Quick Start Guide Table 2-1: Device Revision 9 and 10 (HART7), DD Revision 1 Fast Key Sequence (continued) Function Fast Key sequence HART 7 HART 5 Descriptor 2, 2, 7, 1, 5 2, 2, 7, 1, 4 Digital to Analog Trim (4 - 20 mA Output) 3, 4, 2 3, 4, 2 Disable Configuration Buttons...
  • Page 14 Quick Start Guide March 2020 Figure 2-9: Internal and External LOI Buttons Internal buttons External buttons Note Figure 2-10 to confirm external button functionality. Table 2-2: LOI Button Operation Button SCROLL Left ENTER Right Emerson.com/Rosemount...
  • Page 15 March 2020 Quick Start Guide Figure 2-10: LOI Menu Assign PV HART Revision 2.5.4 Switch HART revision mode If the HART configuration tool is not capable of communicating with HART Revision 7, the Rosemount 3051 will load a generic menu with limited capability.
  • Page 16 Step 3: Connect the wiring and power up for instructions). 2. Follow the HART menu to perform the desired zero trim. Table 2-3: Zero Trim Fast Keys Analog zero (Set 4 mA) Digital zero Fast Key sequence 3, 4, 2 3, 4, 1, 3 Emerson.com/Rosemount...
  • Page 17 March 2020 Quick Start Guide Figure 2-11: External Configuration Buttons Analog Zero and Span Digital Zero Configuration buttons Use the following procedures to perform a Zero Trim: Perform trim with LOI (option M4) Procedure 1. Set the transmitter pressure. 2. See Figure 2-10 for the operating menu.

  • Page 18: Safety Instrumented Systems Installation

    Quick Start Guide March 2020 Safety instrumented systems installation For Safety Certified installations, please refer to Reference Manual installation procedure and system requirements. Emerson.com/Rosemount...

  • Page 19: Product Certifications

    A copy of the EU Declaration of Conformity can be found at the end of the Quick Start Guide. The most recent revision of the EC Declaration of Conformity can be found at Emerson.com/Rosemount. Ordinary Location Certification from FM Approvals...
  • Page 20 EN60079-0:2012 + A11:2013, EN60079-1:2013, Standards used: EN60079-26:2015, EN60079-31:2009 Markings: II 1/2 G Ex db IIC T6…T4 Ga/Gb, T6(-60 °C ≤ T ≤ 70 °C), T5/T4(-60 °C ≤ T ≤ 80 °C); II 1 D Ex t IIIC T50 °C T °C Da Emerson.com/Rosemount...
  • Page 21 March 2020 Quick Start Guide Table 4-1: Process Connection Temperature Temperature class Process connection Ambient temperature temperature -60 °C to +70 °C -60 °C to +70 °C -60 °C to +80 °C -60 °C to +80 °C -60 °C to +120 °C -60 °C to +80 °C Special Conditions for Safe Use(X): 1.
  • Page 22 1. This apparatus is not capable of withstanding the 500V insulation test that is required by EN60079-15. This must be taken into account when installing the apparatus. 2. Some variants of the equipment have reduced markings on the nameplate. Refer to the Certificate for full equipment marking. Emerson.com/Rosemount...
  • Page 23 March 2020 Quick Start Guide International E7 IECEx Flameproof Certificate: IECEx KEM 06.0021X Standards: IEC 60079-0:2011, IEC 60079-1:2014, IEC 60079-26:2014 Markings: Ex db IIC T6…T4 Ga/Gb T6(-60 °C ≤ T ≤ +70 °C ), T5/T4(-60 °C ≤ T ≤ +80 °C) Table 4-3: Process Connection Temperature Temperature class Process connection...
  • Page 24 Special Conditions for Safe Use(X): 1. This device contains a thin wall diaphragm less than 1 mm thickness that forms a boundary between zone 0 (process connection) and zone 1 (all other parts of the equipment). The model code and Emerson.com/Rosemount...
  • Page 25 March 2020 Quick Start Guide datasheet are to be consulted for details of the diaphragm material. Installation, maintenance and use shall take into account the environmental conditions to which the diaphragm will be subjected. The manufacturer's instructions for installation and maintenance shall be followed in detail to assure safety during its expected lifetime.
  • Page 26 Combination of E5 and I5 Combination of C6, E8 and I1 Combination of E8, I1 and N1 Combination of E5, I5 and C6 Combination of E8, I1, E5, I5 and C6 Conduit plugs and adapters IECEx Flameproof and Increased Safety Emerson.com/Rosemount...
  • Page 27 March 2020 Quick Start Guide Certificate: IECEx FMG 13.0032X Standards: IEC60079-0:2011, IEC60079-1:2007, IEC60079-7:2006-2007 Markings: Ex de IIC Gb ATEX Flameproof and Increased Safety Certificate: FM13ATEX0076X Standards: EN60079-0:2012, EN60079-1:2007, IEC60079-7:2007 Markings: II 2 G Ex de IIC Gb Table 4-5: Conduit Plug Thread Sizes Thread Identificati on Mark...
  • Page 28 Quick Start Guide March 2020 Declaration of Conformity Emerson.com/Rosemount...
  • Page 29 March 2020 Quick Start Guide Quick Start Guide...
  • Page 30 Quick Start Guide March 2020 Emerson.com/Rosemount...
  • Page 31 March 2020 Quick Start Guide Quick Start Guide...
  • Page 32 Quick Start Guide March 2020 China RoHS table Emerson.com/Rosemount...
  • Page 33 March 2020 Quick Start Guide Quick Start Guide...
  • Page 34 Quick Start Guide March 2020 Emerson.com/Rosemount...
  • Page 35 March 2020 Quick Start Guide Quick Start Guide...
  • Page 36 The Emerson logo is a Twitter.com/Rosemount_News trademark and service mark of Emerson Electric Facebook.com/Rosemount Co. Rosemount is a mark of one of the Emerson Youtube.com/user/ family of companies. All other marks are the RosemountMeasurement property of their respective owners.
