Component Location

See Figure 5-1.
1
1
2
3
4
5
4181381 First Edition
2
5
4
Traction Drive Motor
Traction Drive Motor Harness Connector
Traction Drum/Differential Assembly
Traction Drive Motor Pulley
Traction Drive Belt (Transfer)
Figure 5-1: Power Train Component Location
3
6
7
8
9
6 Traction Drive (Outer Transfer) Pulley
7 Traction Drive (Inner Transfer) Pulley
8 Traction Drive Belt (Final Drive)
9 Traction Drive (Traction Drum) Pulley
POWER TRAIN
5
TN0761, 0762, 0808
5-3
