EZVIZ C1C Indoor Cube Camera Manual

Box Content

Box Content

information The camera appearance is subject to the actual one you have bought.

Basics

Overview

Parts Description

LED Indicator:

  • Solid Red: Camera is starting up.
  • Slow-flashing Red: Wi-Fi connection has failed.
  • Fast-flashing Red: Device exception (e.g. microSD card error).
  • Solid Blue: Video is being viewed or played back in EZVIZ App.
  • Fast-flashing Blue: Camera is ready for the Wi-Fi connection.
  • Slow-flashing Blue: Camera is running properly.

microSD Card:

  • microSD Card should be purchased separately.
    Initialize the card in the EZVIZ app before using it.

RESET Button

  • Hold down the RESET button for 5 seconds while the camera is running, the camera restarts and all parameters are reset to default.

Setup

Power-on

Plug the power cable into the camera and to the power adapter and then into a power outlet, as shown in the figure below.

Power-on

Camera Setup

  1. Create a user account
    • Connect your mobile phone to Wi-Fi.
    • Download and install the EZVIZ app by searching "EZVIZ" in App Store or Google PlayTM.
    • Launch the app and register for an EZVIZ user account following the start-up wizard.
  2. Add a camera to EZVIZ
    • Log in the EZVIZ app.
    • From the EZVIZ app Home screen, tap "+" on the upper-right hand corner to go to the scan QR code interface.
       Add a camera to EZVIZ
  • Scan the QR Code on the bottom of the camera.
    Scan the QR Code
  • Follow the EZVIZ app wizard to finish Wi-Fi configuration.

information Please make sure your phone is connected to the 2.4GHz Wi-Fi from the router for Wi-Fi configuration.

Installation

Install the Metal Plate (Optional)

Pick a clean and flat surface and secure the metal plate to the desired position with the foam stickers or screws (not included).

warning There's a magnet piece inside the camera. You can skip this step if the surface is made of metal.

Install the Camera

Secure the camera magnetically to the metal plate or metal surface (see figure below).
Install the Camera

Complete Installation

Adjust the camera angle as required.

Install Memory Card

Insert a microSD card into the slot until a click.

Initializing Memory Card

  1. In the EZVIZ app, check the memory card status by tapping on the Storage Status in the Device Settings interface.
    Tap on the Storage Status in the Device Settings interface
  2. If the memory card status displays as Uninitialized, tap to initialize it.
    The status will then change to Normal.

EZVIZ Connect

Use Amazon Alexa

These instructions will enable you to control your EZVIZ devices with Amazon Alexa. If you run into any difficulties during the process, please refer to Troubleshooting.
Before you start, make sure that:

  1. EZVIZ devices are connected to the EZVIZ app.
  2. In the EZVIZ app, turn off the "Video Encryption" in the Device Settings page.
  3. You have an Alexa-enabled device (i.e Echo Spot, Echo-Show, Allnew Echo-Show, Fire TV (all generations), Fire TV stick (second generation only), or Fire TV Edition smart TVs).
  4. The Amazon Alexa app is already installed on your smart device, and you have created an account.
    To Control EZVIZ devices with Amazon Alexa:
    1. Open the Alexa app and select "Skills and Games" from the menu.
    2. On the Skills and Games screen, search for "EZVIZ", and you will find "EZVIZ" skills.
    3. Select your EZVIZ device's skill, then tap ENABLE TO USE.
    4. Enter your EZVIZ username and password, and tap Sign in.
    5. Tap the Authorize button to authorize Alexa to access your EZVIZ account, so that Alexa can control your EZVIZ devices.
    6. You will see "EZVIZ has been successfully linked", then tap DISCOVER DEVICES to allow Alexa to discover all your EZVIZ devices.
    7. Go back to Alexa app menu and select "Devices", and under devices you will see all your EZVIZ devices.

Voice Command

Discover a new smart device via the "Smart Home" menu in the Alexa app or the Alexa Voice Control function.
Once the device is found, you can control it with your voice. Speak simple commands to Alexa.

information Your device's name for example: "show xxxx camera," can be changed in the EZVIZ app. Each time you change the name of the device, you will need to discover the device again to update the name.

Troubleshooting

What should I do if Alexa fails to discover my device?
Check if there are any Internet connecting problems.
Try to restart the smart device and re-discover the device on Alexa.

Why the device's status is "Offline" on Alexa?
Your device might have been disconnected from the network.
Restart the smart device and re-discover on Alexa.
Check if your router is connected to the Internet and try again.

information For details about countries where Amazon Alexa is available, see Amazon Alexa's official website.

Use Google Assistant

With the Google Assistant, you can activate your EZVIZ device and watch live by speaking Google Assistant voice commands.
The following devices and apps are required:

  1. A functional EZVIZ app.
  2. In the EZVIZ app, turn off the "Video Encryption" and turn on the "Audio" in the Device Settings page.
  3. A TV with functional Chromecast connecting to it.
  4. The Google Assistant app on your phone.

To get started, follow the steps below:

  1. Set up the EZVIZ device and make sure it works properly on the app.
  2. Download the Google Home app from the App Store or Google Play StoreTM and log into your Google account.
  3. On the Myhome screen, tap "+" on the upper-left corner, and select "Set up device" from the menu list to go to the Set up interface.
  4. Tap Works with Google, and search for "EZVIZ", where you will find "EZVIZ" skills.
  5. Enter your EZVIZ username and password, and tap Sign in.
  6. Tap the Authorize button to authorize Google to access your EZVIZ account, so that Google can control your EZVIZ devices.
  7. Tap Return to app.
  8. Follow the above steps to complete the authorization. When synchronization is completed, EZVIZ service will be listed under your list of services. To see a list of compatible devices under your EZVIZ account, tap on the EZVIZ service icon.
  9. Now try some commands. Use the name of the camera that you created when you set up the system.

Users can manage devices as a single entity or in a group. Adding devices to a room allows users to control a group of devices at the same time using one command.

See the link for more information:
https://support.google.com/googlehome/answer/7029485?co=GENIE.

information For additional information about the device, please refer to www.ezviz.com/eu.

COPYRIGHT © Hangzhou EZVIZ Software Co., Ltd.. ALL RIGHTS RESERVED.
Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou EZVIZ Software Co., Ltd. (hereinafter referred to as "EZVIZ"). This user manual (hereinafter referred to as "the Manual") cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of EZVIZ. Unless otherwise stipulated, EZVIZ does not make any warranties, guarantees or representations, express or implied, regarding to the Manual.

About this Manual
The Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the ™ website (http://www.ezviz.com).

Revision Record
New release – January, 2021
Trademarks Acknowledgement
™, ™, and other EZVIZ's trademarks and logos are the properties of EZVIZ in various jurisdictions. Other trademarks and logos mentioned below are the properties of their respective owners.

Legal Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED "AS IS", WITH ALL FAULTS AND ERRORS, AND EZVIZ MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL EZVIZ, ITS DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF EZVIZ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL EZVIZ'S TOTAL LIABILITY FOR ALL DAMAGES EXCEED THE ORIGINAL PURCHASE PRICE OF THE PRODUCT.

EZVIZ DOES NOT UNDERTAKE ANY LIABILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE AS THE RESULT OF PRODUCT INTERRUPTION OR SERVICE TERMINATION CAUSED BY: A)

  1. IMPROPER INSTALLATION OR USAGE OTHER THAN AS REQUESTED;
  2. THE PROTECTION OF NATIONAL OR PUBLIC INTERESTS;
  3. FORCE MAJEURE;
  4. YOURSELF OR THE THIRD PARTY, INCLUDING WITHOUT LIMITATION, USING ANY THIRD PARTY'S PRODUCTS, SOFTWARE, APPLICATIONS, AND AMONG OTHERS. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS. EZVIZ SHALL NOT TAKE ANY RESPONSIBILITES FOR ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, EZVIZ WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.SURVEILLANCE LAWS AND DATA PROTECTION LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS TO THE APPLICABLE LAW. EZVIZ SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES. IN THE EVENT OF ANY CONFLICTS BETWEEN THE ABOVE AND THE APPLICABLE LAW, THE LATTER PREVAILS.
