Take reasonable precautions to prevent electrostatic discharge to the device when installing, servicing or during operation. Discharge
accumulated static electricity by touching one's hand to a well-grounded object before working with the device.
Device Markings
Certain markings (symbols) can be found on the side of the product and are defined as follows:
Symbol
CE marking: the device conforms to the requirements of applicable EC directives.
UKCA marking: the device conforms to the requirements of applicable Great Britain regulations.
UL marking: conforms to the requirements of the UL certification.
FCC marking: This device complies with FCC rules part 15, subpart B, class B.
Warning Symbol: Significant information required. Refer to the Hardware Installation Guide.
Device Information
85.5
[3.37]
Figure 1:
UNITOUCH Dimensions
2 / 7
19
5
[0.75]
[0.2]
131.5
[5.18]
Description
Front View of Back
Mounting Plate
5
10
[0.20]
[0.40]
21
[0.83]
5 [0.20] 7 [0.28]
7 [0.28]
56
58
[2.20]
[2.28]
82
[3.23]
mm
[Inches]
