- Page 1 User Manual MC14-2,4 A 2023-01 © 2022 Cambrionix Ltd. Todos los derechos reservados.
-
Page 2: Table Of Contents
1. Table of Contents 1. Table of Contents 2. Your MC14-2,4 A at a glance 3. Safety 3.1. Signal word panel 3.2. Safety alert symbol 3.3. Pictograms 3.4. Product modification 3.5. Power supply 3.6. Storage and Installation 4. Getting Started 4.1. - Page 3 6.7. Software troubleshooting 7. Disposal 8. Returns and Damaged Products 8.1. What do I do if my order arrives and something the product is faulty or is physically damaged? 8.2. What happens after I have requested a Return? 9. Compliance and Standards MC14-2,4 ...
-
Page 4: Your Mc14-2,4 A At A Glance
12 W of charging power to each of its 14 USB 2.0 tipo A ports, allowing mobile devices to be charged quickly, safely and reliably. All ports can be controlled using Cambrionix software to enable charging whilst monitoring important port and device information. -
Page 5: Safety
3. Safety This user manual is for informational purposes only, it contains information for the start-up and operation of this product. Note: the contents and the product described are subject to change without notice. To avoid injuries and damage, observe the safety instructions in the user manual. -
Page 6: Safety Alert Symbol
Mandatory regulation 3.4. Product modification Cambrionix products are designed and manufactured to meet the requirements of UK and International safety regulations. Modifications to the product could affect safety and render the product non-compliant with relevant safety standards, resulting in injury or damage to the product. -
Page 7: Power Supply
PRECAUCIÓN Fire, or personal injury may occur Do not obstruct air vents on the product. Do not cover the product in combustible material. PRECAUCIÓN Damage to your product may occur Do not bend or compress any part of the product. 3.5. -
Page 8: Storage And Installation
Do not place the power cord near heat sources. Connect the plug to an earthed socket. PRECAUCIÓN Damage to your Cambrionix product may occur Operate the product only in an environment where the ambient temperature is inside the operating temperature range. -
Page 9: Getting Started
4. Getting Started This manual provides a reference for end-users installing for the first time and using their hub after that. As well as a guide for product safety-related information. The MC14-2,4 A is intended to be used in an indoor static environment in which the environment falls within the tested specifications to provide charge, sync and management functionality. -
Page 10: Conexión A La Red Eléctrica
Parte Descripción número de parte Cable de alimentación de la UE 200329 Cable de alimentación australiano 200337 Cable de alimentación IND 200341 4.3. Conexión a la red eléctrica Connect the Power Supply Unit (PSU) to the hub using the DIN de 4 pines plug. Conecte el cable de alimentación a la fuente de alimentación. -
Page 11: Registration
4.6. Registration You may register your product at www.cambrionix.com/product-registration 4.7. Help and Support FAQs and help can be found on the Help page here www.cambrionix.com/help_pages/help. You can raise a support ticket for more in depth support here https://cambrionix.atlassian.net/servicedesk/customer/portals You can also download any of our manuals and keep up to date at the link here www.cambrionix.com/product-user-manuals... -
Page 12: Cleaning Your Mc14-2,4 A
If there is a dirt/ spillage over a ventilation slot, external data/ power connector or product aperture, please remove power from the unit without touching the liquid and contact Cambrionix immediately Asegúrese de que el producto esté apagado y de que el cable de alimentación se haya desconectado del producto. -
Page 13: Product Specifications
5. Product Specifications The MC14-2,4 A is manufactured in the UK 5.1. Requisitos de la alimentación entrante Voltaje de entrada 12 V CC Corriente de entrada 15 A Conexión de entrada DIN de 4 pines 5.2. Potencia de salida Voltaje de salida 5,0 ... -
Page 14: Información Empaquetada
(available from what's included section) These can be ordered from the reseller or solution partner you purchased your MC14-2,4 A from, or from Cambrionix directly. Para encontrar uno de nuestros socios locales, visite www.cambrionix.com/partners donde puede obtener información sobre los proveedores y distribuidores locales que pueden ayudarlo... -
Page 15: Power Supply
5.7. Power Supply Input Voltage 100-240VAC 4A @ 115VAC Input Current 2A @ 230VAC Input Frequency 50-60Hz Input Connector Output Voltage Output Current Output Power (Max) 180W Output Connector 4-pin DIN MC14-2,4 A Página 14 de 23... - Page 16 Dimensions 210 x 85 x 46mm Alfiler Función *-V está conectado a tierra de entrada de CA. MC14-2,4 A Página 15 de 23...
-
Page 17: Troubleshooting
6. Troubleshooting If you experience any issues with your MC14-2,4 A; please try the following solutions, if your issue is not addressed in this section, please get in touch with your local vendor or Cambrionix. 6.1. Initial troubleshooting tips Some tips and information to check first. -
Page 18: Device Connection
es decir, si el LED parpadea lo siguiente: BBBB SLSSSLSS, el número binario es 01000100. 6.4. Device connection. If you are having device connection issues please read through the following common solutions to see if this resolves your observed behaviour. Device issues when updating We have found that during updates on some devices the connection can be dropped or lost on the device, this is due to devices going in and out of the bootloader and requiring different... -
Page 19: Hub Connection Issues
If you have done this step and it still does not work, go to Developer Options and click ‘Revoke USB debugging authorisations’. Unplug the cable and reconnect. If this still doesn’t work, turn off the developer options at the top, re-enable it, and re- enable ‘USB Debugging’. -
Page 20: No Gui
If you are using a headless system with no GUI, then and you require to enable logging for support issues, you can use the following command to create the logging cfg file manually: echo *=debug>/etc/opt/cambrionix/cambrionix.log.cfg Then after re-producing the problem, you can zip the logs from the folder /var/log/cambrionix MC14-2,4 ... -
Page 21: Software Troubleshooting
You may delete the file below when you are finished with it. /etc/opt/cambrionix/cambrionix.log.cfg 6.7. Software troubleshooting Some users have noted that the API can cause a high level of CPU usage. This can sometimes be linked to the API recorder service. If you are finding this and you are not using it then we would reccommend to uninstall it from your system entirely. -
Page 22: Disposal
August 12, 2005, and should not be disposed of as unsorted municipal waste. Please utilize your local WEEE collection facilities in the disposition of this product and otherwise observe all applicable requirements. Cambrionix PRN (Producer Registration Number) For the UK is "WEE/BH191TT". MC14-2,4 A Página 21 de 23... -
Page 23: Returns And Damaged Products
8.2. What happens after I have requested a Return? If you have not purchased the Product(s) direct from Cambrionix please contact the vendor the item was originally purchased from for their returns process. -
Page 24: Compliance And Standards
9. Compliance and Standards Certificado CB Probado y marcado CE Probado y marcado según la Parte 15 de la FCC Cumplimiento de RoHS Probado independientemente por Underwriters Laboratory (UL) con el número de expediente #E346549 Cumple los requisitos de seguridad de la norma EN 60950 para equipos informáticos MC14-2,4 ... - Page 25 The Maurice Wilkes Building Cowley Road Cambridge CB4 0DS Reino Unido +44 (0) 1223 755 520 enquiries@cambrionix.com www.cambrionix.com Cambrionix Ltd es una empresa registrada en Inglaterra y Gales con el número de empresa 06210854 2023-01 © 2022 Cambrionix Ltd. Todos los derechos reservados.
