Introduction

The Model T32840 Sliding Log Miter Table cuts
0°–45° angles left or right on vertical wood-cutting
bandsaws when used with the T32838 Bandsaw
Sled. The miter body features adjustable stops at
90°, 30° left, and 30° right.

Inventory

Description
A. Work Stop ................................................... 1
B. Fence.......................................................... 1
C. T-Bolts
⁄ "-20 x 1
1
4
D. Knobs
⁄ "-20 ............................................... 3
1
4
E. Miter Table .................................................. 1
F.
Flat Washer ⁄ " ........................................... 1
1
4
G. Hex Bolt
⁄ "-20 x
1
4
B
A
D
E
Figure 1. T32840 inventory.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ " .................................... 2
1
2
⁄ " ................................... 1
1
2
C
F
COPYRIGHT © NOVEMBER, 2021 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 11/21) #CS22153 PRINTED IN TAIWAN
MODEL T32840
SLIDING LOG MITER
If you cannot find item on list, check around/
inside packaging materials. Often, items
get lost in packaging while unpacking or
they are pre-installed at factory.

Assembly

Qty
The Model T32840 must be assembled before it
can be mounted on the T32838 bandsaw sled.
To assemble miter table:
1.
Slide (2)
(see Figure 2).
G
Figure 2. T-bolts installed in fence T-slot.
TABLE
INSTRUCTIONS
