Universal Tablet and Phone Adjustable Desk Mount
CONTENTS:
A
INSTALLATION:
1. Attaching Phone Holder to Articulating Arm
3. Attaching Device to Holder
D
3A. Use both hands to extend
the holders. Make sure that your
device size is compatible with
each of the holder.
INSTALLATION - MANUAL
x1
D
C
1A. Rotate in the phone holder
in the articulating arm adapter
until securely tightened.
B
3B. Insert your device inside the holder
and release it to contract it.
PAD-TPADM
B
C
x1
x1
2. Attaching Articulating Arms to Base
2A. Slide the articulating arm into the dedicated mount location
on the base. Rotate in screw until moderately tightened with
your hand, no extra tools needed. Repeat to the other side.
Optional. Attaching Adhesive Pads
Stick the (4) adhesives (F) below the base as shown for added
stability as needed.
D
x1
B
E
A
E
x2
F
x4
x4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CTA PAD-TPADM
Summary of Contents for CTA PAD-TPADM
- Page 1 Universal Tablet and Phone Adjustable Desk Mount PAD-TPADM INSTALLATION - MANUAL CONTENTS: INSTALLATION: 1. Attaching Phone Holder to Articulating Arm 2. Attaching Articulating Arms to Base 1A. Rotate in the phone holder 2A. Slide the articulating arm into the dedicated mount location in the articulating arm adapter on the base.
- Page 2 Portrait & Landscape Tilt Adjustability Adjustability Rotate each holder to the desired orientation. Rotate each joint to create the desired setup. Base Swivel Adjustability Cable Management Rotate to the desired angle. Securely tighten the Use hooks to route cable out of the way. bottom screw to create a more fixed setup.
