A.3. ZIP

Zone 3 will have permission to release Package 2 into Zone 2 once Package 1 has hit zone 2 sensor.

A.4. Zone Hold

If Zones 2 and 3 were put into Zone Hold, Package 2 will be held in Zone 3 when it is detected by the Zone 3 sensor.
Zone 2 would attempt to hold Package 1, however depending on Package 1 position at the time it may be pulled into
Zone 1.

Figure 23: ZIP (Operating Mode)

Figure 24: Zone Hold (Singulate, ZIP, and Slug Modes)

ZoneLogix™ PRO Branch Monitor Guide | Revision 0.1 September 2019 | Page 35
