Fault LED (Red)

8.1.2

Motor LED (Amber)

8.1.3

Table 9: Fault LED

Fault LED Description
OFF No fault is present
Zone Communications, Invalid Branch Configuration,
1 flash (in 5 sec)
or Unsupported Zone Controller in Branch
Power input over voltage ... reduce voltage.
2 flashes (in 5 sec)
Proper range is 22-28 VDC.
Power input under voltage – increase voltage.
3 flashes (in 5 sec)
Proper range is 22-28 VDC.
Motor Connection. Check that cable is secured and
4 flashes (in 5 sec)
not damaged.
5 flashes (in 5 sec) Zone Controller Over Temperature
6 flashes (in 5 sec) Extreme Motor Over Current
7 flashes (in 5 sec) Product model does not match Master
8 flashes (in 5 sec) Software version does not match Master
Motor Stalled, Sensor Blocked, or Firmware Update in
ON Constant
Process

Table 10: Motor Current LED

Motor Current LED Description
OFF Motor is not being current limited
Motor in intermittent current limit. Can occur when
starting motor with heavy loads. If flickering
Flickering
constantly, this indicates the motor is operating at
max limit and may not reach full speed.
Motor at max current limit. Check for mechanical
ON Constant
obstruction.
ZoneLogix™ PRO Zone Controller User Guide | Revision 1.0 November 2019 | Page 32
