Firmware Version Display

8.2
Three (3) of the feedback LEDs are used to communicate the firmware revision of the Zone Controller during the start-
up sequence. Each time that power is applied to the board, the
immediately. After 1 second the
1.5 seconds represents a decimal point separating major revisions from minor revisions. An example is shown below:
The example sequence above represents firmware revision 1.2. When the
sequence has ended, and normal operation begins.

Additional Assistance

8.3
For updated revisions to our user manuals, visit our website:
For additional assistance, please contact:
Sales / Customer Service
(619) 677-6530
9

Document Revision History

The following changes have been made to this document:
amber LED flashes on for 0.75 seconds followed by an off period. An off period of

Figure 20: Firmware Version Display Example

Rev: Date: Summary:
1.0 November 2019 Original Release.
green (power) and red (fault) LEDs light up
red (fault) LED turns off, the start-up
