Operations Manual: AEx Series

SPECIFICATIONS AND DIMENSIONAL OUTLINES

AT A GLANCE:
SPECIFICATIONS:
Connector Type
I/O Ports
Display Interface
On-Screen Display
Touch Screen
Interface
Light Transmission
Display Type
Resolution
Display Max. Color
Luminance (cd/m²)
View Angle (H°/V°)
Contrast Ratio
Backlight Lifetime (hrs)
Electrical
Input Voltage
Input Current
Input Power
Dimension
(W x H x D)
Mechanical
Net Weight
Construction
Mounting
Operating Temperature
Storage Temperature
Relative Humidity
Environmental
Certifications
* AEx units come provided with the following I/O cables; M12 waterproof connectors for PC side, other end of
I/O cable is corresponding specified connector type:
•
•
•
Notes •
I/O cable length: 10', Power cable length: 15'
Specifications subject to change without notice.
Operations Manual: AEx Series
•
CSA C1D2, C2D2, C3, ATEX / IECEx Zone 2, Zone 22
Certified for Use in Harsh Environments
•
High Brightness Sunlight Readable (1000 Nits)
Optically Bonded TFT LCD
•
Extended Operating Temperature (-20~60°C)
•
316 Stainless Steel Chassis with IP66 Rating on All Sides
•
Included 10' External On-Screen Display Controller
Audio
Power
USB
Type
15.0" XGA TFT LCD
15.71 x 12.76 x 2.76 inches
[399 x 324 x 70 mm]
Approx. 18.74 lbs [8.5 kg]
Rating
1x USB 2.0 Type A
1x VGA
1x Power cable
1x OSD (On-Screen Display) Controller
M12, with waterproof cover and tether chain*
N/A
1 x M12 3-pin for DC power input (leads)*
1 x M12 12-pin for VGA*
1 x M12 8-pin for 2 x USB 2.0 type A*
1 x M12 8-pin for External OSD Controller Box
Projected Capacitive
USB
90+%
1024 x 768
262K
1000
160/140
800:1
50,000+
9-36 VDC
0.63-2.53 A
22.8 W
316 Stainless Steel Chassis
VESA 100 x 100 mm
-4~140°F [-20~60°C]
-22~158°F [-30~70°C]
10 to 95% @ 40°C, non-condensing
IP66
ATEX / IECEx Zone 2 Ex ec ic IIC T4 Gc
ATEX / IECEx Zone 22 Ex tc IIIC T135°C Dc
Class I Division 2 Group A, B, C, D, T4
Class II Division 2 Group F, G, T135°C
Class III
ANSI/ISA 12.12-01-2013
CSA Std. C22 No213-1987, C22.2 No.61010
CE / FCC Class A / RoHS
6
19.0" SXGA TFT LCD
1280 x 1024
16.7M
1000
170/160
1000:1
70,000+
9-36 VDC
1.34-5.37 A
48.3 W
18.50 x 15.30 x 2.95 inches
[470 x 388.6 x 75 mm]
Approx. 25.35 lbs [11.5 kg]
