Universal Security Grip Kiosk Stand
CONTENTS:
A
x1
INSTALLATION:
1. Assembling Base to Body
J
Optional
Locking Base Rotation
J
Turn clockwise with provided tool to prevent body
rotation using the provided allen key tool (J).
INSTALLATION - MANUAL
B
x1
C
x1
A
1A. Align holes at the base (B)
with the holes on the base of
the body (A). Screw in bolts (E)
B
with the provided allen key tool
(J) as shown.
E
**Cables shown for illustration
and NOT INCLUDED.
PAD-USGTW
F
D
x4
x2
M5 x 12
E
G
x4
x4
M5 x 8
M5 Hex Nut
2. Cable Routing / Cable Management
B
2A. Identify the hole at the bottom of the
base (B) through where cable routing
should go. Then, fish the cable.
Mounting into Surface
**Screwdriver shown for
illustration and NOT
INCLUDED.
I
H
For a more permanent static setup, use a screwdriver (not included) and rotate in 3 screws
(I) as illustrated into 3 predrilled holes with the anchors (H) inserted until securely fastened.
I
x3
J
x1
H
M5 Allen Key
x3
**Cables shown for illustration
and NOT INCLUDED.
A
2B. Fish the cord through the base and out of the top
to properly tuck away cord as shown above.
Optional
K
x1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CTA PAD-USGTW
Summary of Contents for CTA PAD-USGTW
- Page 1 Universal Security Grip Kiosk Stand PAD-USGTW INSTALLATION - MANUAL CONTENTS: M5 x 12 M5 Allen Key M5 x 8 M5 Hex Nut INSTALLATION: 1. Assembling Base to Body 2. Cable Routing / Cable Management **Cables shown for illustration and NOT INCLUDED.
- Page 2 3. Inserting Tablet into Holder **Tablet shown for illustration and NOT INCLUDED. 3A. Take the holder (C) and insert the key (K) to make sure you have the arms unlocked. 3B. Retract the holder on the outside of the tablet as illustrated. Lock the key to secure into Extend the arms out to match the corners of the tablet (not included).
