05/19/2011
Ins-30150-US Net2 Caller ID/GSM Access Reader
Technical Support
1.800.672.7298
Technical help is available:
Documentation on all Paxton products can be found on our web site - http://www.paxton-access.com/
SIM card not supplied
(Optional)
Due to the regional and local requirements for specific cell phone coverage you will need to purchase the SIM
card required for your area. For example, Verizon or AT&T. Most electronic stores, such as Best Buy and Fry's
Electronics, carry SIM cards.
WHAT YOU NEED TO LOOK FOR:
1.
SIM Card that works for UNLOCKED phones.
2.
SIM Card Service that allows automatic charging.
3.
The service with lowest monthly payment because the unit does not extract any minutes off the plan.
The best plan is the fewest minutes and the most months.
The SIM Card Service will provide the Phone number that you will call to access the Caller ID reader.

FCC Compliance

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation. Changes or modifications not
expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.
Monday - Friday from 02:00 AM - 8:00 PM (EST)
12V
LED
LED
Paxton
Caller ID
LED
Data/D0
Clock/D1
0V
support@paxton-access.com
12V
LED
LED
LED
Data/D0
Clock/D1
0V
Connection to the
Net2 ACU reader port
Paxton
Antenna
