Ins-30156 PROXIMITY P series Wiegand output - Biomet
Suitability
Security-sensitive doors
Mounted on metal surface
Fitting
Wire outputs
Cable extensions
Readers can be extended using Belden CR9540 10-core overall screened cable to a maximum of 100 metres.
Readers mounted together
+12V DC
Red LED
Amber LED
Green LED
Data 0
Data 1
Not Required
0V
Wet environments
between readers
Paxton Net2 control unit
300 mm
