Polaris Ranger 570-6 / 800
Crew Steel Roof
Product Instructions | Part No: 29160
Application:
Polaris Ranger Crew 570-6 / 800, verify accessory
fitment at Kolpin.com.
Before You Begin:
Read these instructions and check to be
sure all parts and tools are accounted for. Please retain these
Installation Instructions for future reference and parts ordering
information.
Note: If any hardware is missing, do not return to the
store. Call us to help, Toll Free 1-877-956-5746.
Note: Two people are required to install this Roof Kit.
Items marked (*) are included in Hardware Kit PN 29161.
Tools Required:
Socket Set, Metric
Wrench Set, Metric
Utility Knife/Cutting Tool
5
1
12
13
Torx Bit Set
Torque Wrench
10
4
7
11
10
Kolpin Outdoors, Inc. | 9955 59th Ave N | Plymouth, MN 55442
(877) 956-5746 or (763) 478-5800 |
© 2020 Kolpin Outdoors Inc.
This Kit includes:
Item
Qty
Part Description
1
1
RGR Crew Front Roof Panel
2
1
RGR Crew Rear Roof Panel
3*
3
Button Screw, Zinc Plated, M6 x 1.0 - 20mm LG
4*
15
Flat Washer, Zinc Plated, M6
5*
6
Button Screw, Zinc Plated, M6-1.0 x 25mm LG
6*
6
Button Screw, Zinc Plated, M6-1.0 x 30mm LG
7*
15
Flange Locknut, Zinc Plated, M6-1.0
8*
1
Rear Foam Strip 55" (1400mm)
9*
2
Side Rear Foam Strip 31.25" (794mm)
10*
2
Side Front Foam Strip 22.75" (578mm)
11*
1
Rubber Overlap Trim Seal
12*
10
Clamp, Painted, 1.75" Diameter
13*
1
Front Foam Strip 38.25" (972mm)
14
1
Instruction Guide (not shown)
3
4
www.kolpin.com
|
customerservice@kolpin.com
1
REV 00
9
4
12
7
7
2
6
8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Polaris Ranger 570-6 / 800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kolpin Outdoors Polaris Ranger 570-6 / 800

  • Page 1 Instruction Guide (not shown) • Wrench Set, Metric • Utility Knife/Cutting Tool • Kolpin Outdoors, Inc. | 9955 59th Ave N | Plymouth, MN 55442 (877) 956-5746 or (763) 478-5800 | www.kolpin.com customerservice@kolpin.com © 2020 Kolpin Outdoors Inc. REV 00...
  • Page 2 The Ill. 1-3 alignment marks help locate where the foam strips will be applied. © 2020 Kolpin Outdoors Inc. REV 00...
  • Page 3 M6 screws (item #6) and M6 flat washers (item #4) as shown. (See Note: Do not tighten illustration 1-8). hardware at this step since adjustments may be required later. Ill. 1-6 Ill. 1-7 Ill. 1-8 © 2020 Kolpin Outdoors Inc. REV 00...
  • Page 4 Peripheral products such as engines, electric motors, and actuators may carry an original manufacturer’s warranty. Most hardware is general in nature and is easily obtained locally. Be sure to replace with minimum metric class 8.8 specification. © 2020 Kolpin Outdoors Inc. REV 00...
