Polaris Ranger Mid-Size (Round Tube)
Rear Panel
Product Instructions | Part No: 2732
Application:
Verify accessory fitment at Kolpin.com.
Before You Begin:
be sure all parts are accounted for. If any items are missing,
do not return to the store. Call us at 1-877-956-5746 for assis-
tance. Please retain these instructions for future reference and
parts ordering information.
Dealers:
Provide Instruction Manual to customer at time of
purchase.
Tools Required:
Wrench
Read these instructions and check to
4mm Hex Wrench or Socket, Torque
1
Kolpin Outdoors, Inc. | 9955 59th Ave N | Plymouth, MN 55442
(877) 956-5746 or (763) 478-5800 |
© 2019 Kolpin Outdoors Inc.
Product Contents:
Item Description
1
Rear Windshield Panel
2
Clamp - 1.75" Diameter
3
M6 x 18mm Button Head Screw
4
M6 Lock Washer
5
M6 Domed Shoulder Washer
6
Rubber Clamp Spacer
7
M6 x 38mm Button Head Screw
8
M6 Lock Washer
9
M6 Domed Shoulder Washer
10 14mm Nylon Standoff
11 M6 Shoulder Washer
12 M6 Lock Nut
* Extra Component Quantity Supplied
** Component Not Used
6
3
4
5
10
7
8
9
www.kolpin.com
|
customerservice@kolpin.com
1
REV 02
7
2
4
3
2
6
7
Qty
Part Number
1
8
K100137
*24
(Qty 4)
*24
*16
K100189
4
(Qty 2)
6
6
K100178
6
(Qty 3)
6
**6
**6
8
9
10
2
10
2
8
9
