Post-Installation - Endress+Hauser Proline Promass 40 Brief Operating Instructions

Proline Promass 40
2.3

Post-installation

2.3.1 Turning the transmitter housing
Turning the aluminum field housing
Aluminum field housing for non-Ex area
a
Aluminum field housing for Zone 1 or Class I Div. 1
a
2.3.2 Turning the onsite display
Endress+Hauser
b
c
b
c
r
4 x 45°
b
a
d
£ 180° £ 180°
max. 360°
Nicht-eigensichere
Stromkreise durch
IP40-Abdeckung geschützt
Non-intrinsically safe
circuits Ip40 protected
Boucles de courant
sans sécurité intrinsèque
protégées par Ip40
d
A0008036
a. Press in the side latches on the display module and
remove the module from the cover plate of the
electronics compartment.
b. Turn the display to the desired position (max.
4 x 45° in both directions) and reset it onto the
cover plate of the electronics compartment.
A0007541
Installation
e
f
a. Release the setscrew.
b. Turn the transmitter housing
gently clockwise until the stop
(end of the thread).
c. Turn the transmitter
counterclockwise (max. 360°)
to the desired position.
d. Retighten the setscrew.
A0007540
7
