Atmel ATAN0008: ATAK51001 Quick Start Guide
1. Hardware Requirements
®
The Atmel
ATAK51001 Car Access Reference Design system requires that an
®
STK600 AVR
development board be acquired SEPARATELY. All of the other hard-
ware components are shipped complete with this kit including power supply and all
connecting cables. The demo can be run in stand-alone mode or with a PC GUI used
to display more information content. The key fob devices come fully configured but
require a CR2032 coin cell battery be acquired SEPARATELY.
1.1
Atmel ATAK51001 Hardware Setup
There are four antennas that must be connected to the RF receiver, LF Basestation,
and LF Driver boards respectively. Three 10-pin ribbon cables connect the Interface
board to the Atmel STK600. Be sure to correctly align the red stripe for "Pin 1" prop-
erly. Power is supplied from a wall transformer and a Y-cable. This powers both the
Atmel ATAK51001 hardware as well as the Atmel STK600.
1.2
Atmel STK600 Hardware Setup
Two 10-pin ribbon cables are used to connect the LEDs and Switches on the Atmel
STK600. The connection to the PC is provided through a USB to Serial convertor.
This requires a 2-pin cable be connected to the UART pins. Simply connect all the
hardware as shown in
Figure 1-1 on page 2
by matching the colors.
Atmel
ATAN0008
Application Note
9250A–RKE–11/11
Advertisement
Table of Contents
Related Manuals for Atmel ATAN0008
Summary of Contents for Atmel ATAN0008
- Page 1 LF Driver boards respectively. Three 10-pin ribbon cables connect the Interface board to the Atmel STK600. Be sure to correctly align the red stripe for “Pin 1” prop- erly. Power is supplied from a wall transformer and a Y-cable. This powers both the Atmel ATAK51001 hardware as well as the Atmel STK600.
- Page 2 Figure 1-1. Hardware Connection PORTB PORTD PORTE Atmel ATAN0008 9250A–RKE–11/11...
- Page 3 Status for all events is shown on the Atmel STK600 LEDs and the PC GUI main screen. The PC GUI also includes auditory feedback as well as additional view boxes showing the content of the various messages.
- Page 4 1. Press SW1 (LOCK) or SW2 (UNLOCK) on the key fob 2. LED4 <-- --> LED0 on the Atmel STK600 should cycle left or right respectively if the AES encryption is valid. All other LEDs should be off. (PC GUI should show a Locked...
- Page 5 2. Press SW0 on Atmel STK600 3. LED7 on Atmel STK600 should turn ON and LED4 --> LED0 on the Atmel STK600 should cycle right if the AES encryption is valid. (PC GUI should show an Start icon, green Key Fob, and corresponding sound)
- Page 6 Place STK600 Here Switches LEDs PORTK PORTC RS232 Qprox Door Handle PortJ LEDs <——— PEPS Immo Learn AES Success Passive Entry Learn Modes Buttons Immo Passive <——— Start Start UNLOCK LOCK IMMO CLEAR Atmel ATAN0008 9250A–RKE–11/11...
- Page 7 Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellec- tual property right is granted by this document or in connection with the sale of Atmel products. EXCEPT AS SET FORTH IN THE ATMEL TERMS AND CONDITIONS...
