Quick Start RF Transceiver Evaluation Kit

1. Introduction

The RF Transceiver Evaluation Kit exists to provide familiarity with the functionality of
®
Atmel 's UHF ASK/FSK transceivers. For this purpose, software is included which
enables the user to configure the registers easily and conveniently.

2. Kit Contents

The transceiver kit consists of a transceiver base station board, an SPI2LPT interface
board, a DC supply cable, a parallel port cable, and a CD-ROM with the appropriate
Software, as depicted in
board have to be ordered separately.
Figure 2-1. Kit Contents
Downloaded from DatasheetLib.com
Figure 2-1. The transceiver board and the SPI2LPT interface
- datasheet search engine
Quick Start RF
Transceiver
Evaluation Kit
Application Note
4888B–RKE–07/06
