Thin Mini-ITX Internal Electrical Interfaces
Table 2-12. 2x10 USB 3.0 Header Pin-Out
Pin
1 Vbus
2 IntA_P1_SSRX-
3 IntA_P1_SSRX+
4 GND
5 IntA_P1_SSTX-
6 IntA_P1_SSTX+
7 GND
8 IntA_P1_D-
9 IntA_P1_D+
10 ID
11 IntA_P2_D+
12 IntA_P2_D-
13 GND
14 IntA_P2_SSTX+
15 IntA_P2_SSTX-
16 GND
17 IntA_P2_SSRX+
18 IntA_P2_SSRX-
19 Vbus
20 Key
Thin Mini-ITX Based PC System Design Guide
Signal
Power
USB3 ICC Port1 SuperSpeed Rx-
USB3 ICC Port1 SuperSpeed Rx+
Ground
USB3 ICC Port1 SuperSpeed Tx-
USB3 ICC Port1 SuperSpeed Tx+
Ground
USB3 ICC Port1 D- (USB2 Signal D-)
USB3 ICC Port1 D- (USB2 Signal D+)
Over Current Protection
USB3 ICC Port2 D+ (USB2 Signal D+)
USB3 ICC Port2 D- (USB2 Signal D-)
Ground
USB3 ICC Port2 SuperSpeed Tx+
USB3 ICC Port2 SuperSpeed Tx-
Ground
USB3 ICC Port2 SuperSpeed Rx+
USB3 ICC Port2 SuperSpeed Rx-
Power
Not Connected
Description
27
