Installation and application

Maximum tilt angle
Fig 1. Maximum tilt angle
Off-road applications
The maximum tilt angle allowed in GLT80TDC
compressor (stopped or running) in any of the
2 below mentioned recommended positions
is 20º, and maximum tilt angle in the 2 below
not recommended position is 15º. Apart
from this specification, below diagrams show
the recommended and not recommended
positions while the compressor is running in the
application.
GLT80TDC compressor is not designed for off-
road mobile applications. If you are interested
If compressor has been stopped during a certain
period of time with an inclination higher than
15º, it is strongly recommended to not start
up the compressor immediately after coming
back to the correct position. We recommend
waiting at least 30 minutes before starting up the
compressor.
RECOMMENDED POSITIONS
β max=20º
NOT RECOMMENDED POSITIONS
α max=15º
in this type of mobile applications, it has to be
specifically approved by the manufacturer.
