U-Line H-6482 Installation Instructions

π
H-6482
VERTICAL BABY
CHANGING STATION

TOOLS NEEDED

Phillips Screwdriver
Level
NOTE: The unit must be attached to a
permanent wall that is capable of holding a
substantial load. The maximum recommended
total weight for this baby changing station
(including baby and parcel bag) is 60 lbs.
Excessive weight may cause hazardous or
unstable conditions.
1. Remove changing station from the shipping
container and check for any freight damage.
Identify the best location to install the unit. Hold the
unit in place and open the bed. Make sure you
have taken operating clearance into consideration.
2. Determine the best method of mounting based on
the type of wall. You may have leftover hardware
when installation is finished.
3. The vertical unit has four mounting holes provided in
the back wall, positioned on a 16" stud center.
(See Figure 1)
PAGE 1 OF 2
1-800-295-5510
uline.com
Stud Finder
Baby Changing
Station x 1
Measuring Drill
Tape

PARTS

Flat Washer
x 4

INSTALLATION

If possible, locate the wood or metal wall studs for
fastening the unit in the desired location. If the walls do
not have studs on center as outlined, make sure at least
one side of the unit is installed into the stud.
Figure 1
1/8" and 7/32" 1/8" and 7/32"
Drill Bit Masonry Drill Bit
(if wall is brick or tile)
1/4 x 3" Phillips
Wood Screw x 4
16"
0117 IH-6482
