Pentair STA-RITE JHCX SAE Series Owner's Manual

HORSEPOWER
SINGLE PHASE
MODELS
Key
No. Part Description
1* Motor
2 Water Slinger
3 Seal Plate
4 Gasket
5 Shaft Seal
6 Impeller, Single Phase
6 Impeller, Single Phase Bronze
6A Impeller Screw
7 Volute Assembly - With Wear Ring
7A Wear Ring
8 Pipe Plug Hex Head
9 Base - With Motor Pad
9A Motor Pad
10A Capscrew - 3/8 - 16 x 1" Lg.
10B Capscrew - 3/8 - 16 x 1-1/4" Lg.
*For repair or service to motors, always give the motor Model Number and any other data found on the Motor Model Plate.
( ) For quantities other than those listed in the "No. Used" Column.
© 2020 Pentair plc. All Rights Reserved.
STA-RITE
1/2 HP 3/4 HP
JHCX...SAE JHDX...SAE
JBHCX...SAE JBHDX...SAE
1
9A
9
10B
REPAIR PARTS LIST – "J" SERIES - HIGH HEAD
JHCX...SAE
No. JBHCX...SAE
Used 1/2 HP
1 J218-582A-LSA
1 17351-0009
1 C3-178
1 C20-121
1 U109-6B
1 C105-92PNP
1 C5-256BA
1 –
1 C101-290
1 C23-27
1 U78-941ZPV
1 J204-9
1 C35-5
2 U30-74ZP
2 U30-75ZP
MODELS
1 HP 1-1/2 HP
JHEX...SAE JHFX...SAE
JBHEX...SAE JBHFX...SAE
10A
2
3
JHDX...SAE JHEX...SAE
JBHDX...SAE JBHEX...SAE
3/4 HP 1 HP
J218-590-LSA J218-596-LSA
17351-0009 17351-0009
C3-178 C3-178
C20-121 C20-121
U109-6B U109-6B
C105-92PMP C105-92PLP
C5-256BAA C5-254BA
– –
C101-290 C101-290
C23-27 C23-27
U78-941ZPV U78-941ZPV
J204-9 J204-9
C35-5 C35-5
U30-74ZP U30-74ZP
U30-75ZP U30-75ZP
OWNER'S MANUAL
60 Cycle "J" Series
Centrifugal Pumps
2 HP
JHGX...SAE
JBHGX...SAE
4
5
6
5711 1011 AR
JHFX...SAE JHGX...SAE
JBHFX...SAE JBHGX...SAE
1-1/2 2 HP
J218-601-LSA J218-883A-LSA
17351-0009 17351-0009
C3-178 C3-181
C20-121 C20-122
U109-6B U109-6B
C105-92PBP C105-214PCAP
C5-254BC C5-257BB
C30-14SS C30-14SS
C101-290 C101-289
C23-27 C23-27
U78-941ZPV U78-941ZPV
J204-9 J204-9
C35-5 C35-5
U30-74ZP U30-74ZP
U30-75ZP U30-75ZP
2-1/2 HP
JHHGX...SAE
JBHHGX...SAE
7
8
JHHGX...SAE
JBHHGX...SAE
2-1/2 HP
J218-628A-48-LSA
17351-0009
C3-181
C20-122
U109-6B
C105-214PAP
C5-257B
C30-14SS
C101-289B
C23-27
U78-941ZPV
J204-9
C35-5
U30-74ZP
U30-75ZP
SX489 (3/20/2020)
