14 C 3: C
HAPTER ABLING THE
V6000/V6100 M
EDIA
3 Connect the first Ethernet connection (labeled I), located on the CPU
module of the V6000/V6100 front panel, directly to the network using a
standard RJ-45 Ethernet cable (and the second connection as optional
redundancy / backup). For the connector pinouts, see
Figure 3 RJ-45 Ethernet Connector Pinouts
1 2 3 4 5 6 7 8
For redundancy, 3Com recommends that you connect each of the
Ethernet connectors to a different switch.
When assigning an IP address to the V6000/V6100 using HTTP (see
"Assigning an IP Address Using
cable and re-cable it differently.
4 Using the supplied RS-232 cable, connect the V6000/V6100 RS-232 port
(labeled I0I0) to either the COM1 or COM2 RS-232 communication port
on your PC. Using the RS-232 port is optional.
5 If you want to set up a dry contact system, refer to the User's Manual.
6 Connect the left (active) 100-240V~50-60 Hz power socket to the mains
using the supplied cord.
G
ATEWAYS
1 - Tx+
2 - Tx-
3 - Rx+
6 - Rx-
HTTP"), you may need to disconnect this
Figure 3, next.
4, 5, 7, 8
not
connected
