E-Series Instruction Guide
Important Safety Information
Always read this manual first before attempting to install or use this
fireplace. For your safety, always comply with all warnings and safety
Instructions contained in this manual to prevent personal injury or property
damage.
Please Note: This product is for well insulated spaces or
occasional use.
Please Note: Once your e-series product has been installed and
switched to the ON position, the fire will instantly flash. This is
normal operating procedure, simply indicating that there is power
running to the fire and NOT a fault.
SERIAL NUMBER LABEL
English
E-Series-180724
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Evonic Fires E Series
Summary of Contents for Evonic Fires E Series
- Page 1 INSTRUCTIONS MUST BE KEPT AFTER INSTALLATION IN CASE OF FUTURE MAINTENANCE E-Series Instruction Guide Important Safety Information Always read this manual first before attempting to install or use this fireplace. For your safety, always comply with all warnings and safety Instructions contained in this manual to prevent personal injury or property damage.
-
Page 2: Table Of Contents
Contents Introduction Electrical Safety Important Instructions Installation Method Glass Removal 9/10 Side Conversion Panels 11/14 E-Touch & App Interface Log guidance 16/18 Product operation 19/20 Problem Solving 21/24 Warranty welcome to evonicfires evonicfires is an award-winning brand of CK Fires Ltd, situated just outside Stratford- upon-Avon, we manufacture a range of British built electric fires and are considered as one of the most technically advanced manufacturers in the world, with optional controllers such as e-touch and a fully integrated APP available to download on both... -
Page 3: Electrical Safety
ELECTRICAL SAFETY: When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: ① Read all instructions before using this electric fireplace. ② This fireplace is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. - Page 4 ⑬ Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage to the heater. ⑭ To prevent a possible fire, do not block air intakes or exhaust in any manner.
-
Page 5: Important Instructions
IMPORTANT INSTRUCTIONS: Please read these instructions before installation or use and keep this booklet handy for future reference. All Evonic fires products meet the requirements of the EC Directives. These directives have been met by compliance with the following standards: EU 2011-65/EU 2015/863 Restriction of Hazardous Substances EN 55014-1:2006 + A2:2011 Electromagnetic compatibility. - Page 6 Never use aerosols or steam cleaners near this product. Never route the electric cable near the heater outlet. Never route the electric cable under carpets or floor coverings. Never install this product close to curtains or combustible materials. Never Use the heater to dry clothes or other objects. Never remove the fireplace surrounding without isolating the electric supply.
-
Page 7: Installation Method
INSTALLATION METHOD: PLEASE NOTE: It is crucial to ensure that the product has a minimum internal clearance directly above and below the product of 100 mm, this is to ensure that the product can circulate the required airflow for the heater unit. PLEASE NOTE: Due to the weight of the e2400 model, it must be supported from the bottom of the fire. - Page 8 Please note: This table is only an example of an installation and is only applicable to GF models Please see Figure 1: as a example of a installation. Model Width Depth Height e500 492mm 310mm 609mm Please refer to technical specification table for further E600 637mm 190mm...
-
Page 9: Glass Removal
GLASS REMOVAL:... - Page 10 3. Remove the glass by pulling the second retaining bar away from the body of the fire. Ensure that the glass is supported at all times. A suction cup has been provided to aid with this step. Please note: The suction cup is provided for support only, not to hold the full weight of the glass.
-
Page 11: Side Conversion Panels
SIDE CONVERSION PANELS To complete this step, you must first remove front glass and side glass. ITEM. DESCRIPTION. QTY. SIDE GLASS 2 OFF FRONT GLASS 1 OFF PLASTER KIT (3 OFF LEFT SIDE, 3O FF RIGHT SIDE) 6 OFF MAIN HOUSING 1 OFF FRONT GLASS BOTTOM SUPPORT 1 OFF... - Page 12 STEP 1 - REMOVAL OF FRONT GLASS (ITEM 2) REMOVE THE 2 OFF FIXINGS (ITEM 7) THAT SECURE THE FRONT GLASS BOTTOM RETAINER (ITEM 6) TO THE FUEL BED (ITEM 8). LIFT OFF THE FRONT GLASS RETAINER (ITEM 7) AND USING THE GLASS SUCKERS SUPPLIED (NOT SHOWN) CAEFULLY REMOVE THE FRONT GLASS (ITEM 2).
- Page 13 STEP 2 - REMOVAL OF SIDE GLASS (ITEM 1) REMOVE THE 2 OFF SIDE GLASS TOP RETAINER BRACKETS (ITEM 9) BY TAKING OUT THE 4 OFF FIXINGS (ITEM 10) 2 OFF ON EACH BRACKET. CAREFULLY TILT THE SIDE GLASS INWARDS AT THE TOP AND LIFT IT AWAY FROM UNIT.
- Page 14 STEP 4—FITTING IN-FILL SIDES (ITEM 13 & 14) REMOVE IN-FILL SIDE FIXINGS (ITEM 12) PLACE THE IN-FILL SIDES OVER THE EXISTING SIDE PIECES USING THE IN-FILL SIDE FIXINGS (ITEM 12) TOGETHER WITH THE PLASTER KIT FIXINGS (ITEM 11) THAT WERE REMOVED IN THE PREVIOUS STEP SECURE THE LEFT AND RIGHT IN-FILL SIDES (ITEM 13 &...
-
Page 15: E-Touch & App Interface
E-TOUCH APP INTERFACE The Appliance is operated using the E-Touch App Control. The App Control can be used on either OS or Android operating systems. To obtain the App please visit either the OS App Store Or Google Play and follow the on screen instructions. Screen shot taken from Apple App Store. -
Page 16: Log Guidance
LOG SET GUIDANCE: Please Note: The images shown are suggested Log layouts, the log sets can be arranged to personal preference. MODEL LOG SET & QUANTITY E500 E700 Log Set X1 E600 E700 Log Set X1 E600gf Small Ceramic Log Set X 2 E600S E700 Log Set X 1 E630... - Page 17 E700 X 1 Log Layout-Applicable with E500, E600S, E700S, E630, E730 E700 X 2 Log Layout Applicable with 800, 810 E640 Twig Set X 1 - Applicable with E640GF, E640 OPEN E640 Twig Set X 2 Layout-Applicable with E900GF, E900 OPEN E1000 Log Set X 1 Layout-Applicable with E1030, E1000GF, E1000 OPEN, 710...
- Page 18 E1000 X 1/E700 X 1 Log Layout-Applicable with E1250 E1000 X 2 Log Layout-Applicable with E1500 E1000 X 3 Log Layout-Applicable with E1800, 1560 E1000 X 4 Log Layout-Applicable with E2400...
-
Page 19: Product Operation
PRODUCT OPERATION: The appliance is operated by the e-touch App, the main standby power switch to the e-series product is located to the right of the heater outlet, which is marked with a light bulb image, to activate the product, this switch must be switch to the “ON”... - Page 20 Heater unit cut-out) (This is a safety feature, to safe guard against further damage to the product). If the airflow is restricted the heater will automatically turn off. This is can occur due to incorrect installation or obstruction. To reset the heater function: isolate from the mains power supply.
