BUILT-INS

INSTRUCTION MANUAL

E500

E600

E630

E640

E700

E710

E730

E800

E810

E900

E1000

E1030

BUILT-INS MANUAL ISS. 17

E1250

E1500

E1560

E1800

E2400

Asta

Avesta

Exor

Kallan

Karlstad

Kiruna

EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1

English

Linnea

Lita

Malmo

Motala

Skara

Thoren

Tyrell

Valter

Table of Contents

Need help?

Do you have a question about the E500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Evonic Fires E500

Page 1 English English BUILT-INS BUILT-INS INSTRUCTION MANUAL INSTRUCTION MANUAL E500 E500 E1250 E1250 Linnea Linnea E600 E600 E1500 E1500 Lita Lita E630 E630 E1560 E1560 Malmo Malmo E640 E640 E1800 E1800 Motala Motala E700 E700 E2400 E2400 Skara Skara E710 E710...
Page 2: Table Of Contents
CONTENTS EU Directives and UKCA Standards..............3 Important Information and Health & Safety............4 Components for Evoflame..................5 Components for E-Smart..................6 Installation......................7 Model Dimensions....................8 Installation Process..................10 Converting to GF / GF2 / GF3...............11 Installing the Side Panels / Converting to GF / GF2......12 Requirements and Checks................
Page 3: Eu Directives And Ukca Standards
Particular requirements for room heaters Particular requirements for room heaters UKCA STANDARDS All Evonic Fires products are in conformity with the relevant UK Statutory Instruments All Evonic Fires products are in conformity with the relevant UK Statutory Instruments (and their amendments).
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual.
Page 5: Components For Evoflame
BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 6: Components For E-Smart
BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 7: Installation
INSTALLATION INSTALLATION BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 8: Model Dimensions
MODEL DIMENSIONS The model shown in these drawings is an E1030, however the same processes apply to all Evoflame and E-Smart models. Scan the QR code for more detailed specification drawings. BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 9 MODEL DIMENSIONS Model Width Height Depth With glass With optional Overall Opening Overall GF Only sides (A) side panels unit (B) unit (D) E500 524mm 540mm 609mm 397mm 316mm E600 670mm 686mm 638mm 455mm 196mm E630 670mm 688mm 640mm 455mm...
Page 10: Installation Process
INSTALLATION PROCESS Evoflame or E-Smart Model Evoflame or E-Smart Model (GF2) (GF2) (GF) (GF) (GF3) (GF3) Front & Front & Open Open Glass Glass Front & Front & 1 Glass Side 1 Glass Side Fronted Fronted Fronted Fronted 2 Glass Sides 2 Glass Sides Fit 2 Side Panels Fit 2 Side Panels...
Page 11: Converting To Gf / Gf2 / Gf3
CONVERTING TO GF / GF2 / GF3 The appliance is shipped in the GF3 configuration, however most models can be converted to be GF or GF2 depending on your preference. GF Configuration Glass Fronted A single glass panel at the front of the appliance.
Page 12: Installing The Side Panels / Converting To Gf / Gf2
INSTALLING THE SIDE PANELS / CONVERTING TO GF / GF2 Unscrew and remove the plaster kits from the side/s of the appliance. Screw in the side panel/s, on one or both sides. BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 13: Requirements And Checks
INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • Consult a qualified professional to check the structure of the installation site. • These appliances have been designed to be installed into either a stud and plasterboard wall, or an existing chimney breast.
Page 14 CHECKS BEFORE INSTALLATION We recommend turning on the appliance before installation, connect the appliance to a power source using the provided electrical lead, and depress the right side of the rocker switch. Remove the electrical lead from the wall and continue with the installation. BUILT-INS MANUAL ISS.
Page 15: Installation
TOOLS REQUIRED • Tape Measure • Rear Wall Screws (Masonry type supplied) • Pencil • Top Mounted Bracket Screws x 6 (supplied) • Spirit Level • Top Mounted Bracket Wall Screws x 8 • Screwdriver (supplied) • PZ2 Screw Bit •...
Page 16 Determine the finished height and position that you want the appliance to be located. Then secure the wall bracket to the wall in the position you need using the wall plugs and screws provided. If you’re not securing the appliance to a masonry wall you will need to use the appropriate fixings.
Page 17 Screw the two top mounted brackets to the wall. You can now construct your stud wall/s around the appliance in the design of your choosing. When constructing the studwork, remember that the vents on the underside of the appliance need a minimum of 50mm clearance beneath them.
Page 18 Your plasterboard can now line up with the plaster kits on the edge of the appliance. Alternatively, the chrome side panels can be attached to the case with the magnets as shown below. Ensure that the magnets are positioned with the short side touching the case. BUILT-INS MANUAL ISS.
Page 19: Log Layouts
LOG LAYOUTS LOG LAYOUTS BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 20 1 x Small Woodland / Silver Birch 2 x Small Log Set E500 / E600 Open Fronted / E630 / E700 E600 / E700 Open Fronted / E730/ Thoren / Kallan...
Page 21 4 x Large Woodland / Silver Birch E2400 1 x Medium Split Woodland / Silver Birch Tyrell 1 x Small Split Woodland / Silver Birch Exor / Kiruna / Motala 2 x Small Split Woodland / Silver Birch Asta / Avesta 1 x Large Split Woodland / Silver Birch Linnea / Lita 1 x Small Split Woodland / Silver Birch &...
Page 22: Installing The Side Glass
INSTALLING THE SIDE INSTALLING THE SIDE GLASS PANELS GLASS PANELS BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 23 INSTALLING THE SIDE GLASS PANELS Unscrew and remove the top and bottom glass retainer panels. Slide in the side glass pieces. BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 24: Installing The Front Glass
INSTALLING THE FRONT INSTALLING THE FRONT GLASS PANEL GLASS PANEL BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 25 INSTALLING THE FRONT GLASS PANEL Apply the Suction Lifter to the glass and position the bottom edge of the glass first, then pivot the glass into the appliance. Warning The Suction Lifter is provided to assist in moving the glass NEVER as the sole support of the glass.
Page 26: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING BUILT-INS MANUAL ISS. 17 BUILT-INS MANUAL ISS. 17 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
Page 27 Evoflame Only LED Strip Replacement Scan the QR code to be taken to a video in our maintenance series. Please note; this video shows an old method of removing the front glass panel. Refer to page 24 of this instruction manual for the new method.
Page 28: Warranty & Registration
To register a product please visit: www.evonicfires.co.uk and complete the fields required under the Register a Product Section. By registering your appliance, an extra 12 months will be added to your warranty. CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk...
