    CONTENTS EU Directives and UKCA Standards..............3 Important Information and Health & Safety............4 Components for Evoflame & E-Smart..............5 Installation......................6 Model Dimensions..................7 Requirements and Checks................8 Installation....................9 Log Layouts......................11 Installing/Removing the Front Glass..............13 Troubleshooting....................14 Warranty &...
  • Page 3: Eu Directives And Ukca Standards

    Particular requirements for room heaters Particular requirements for room heaters UKCA STANDARDS All Evonic Fires products are in conformity with the relevant UK Statutory Instruments All Evonic Fires products are in conformity with the relevant UK Statutory Instruments (and their amendments).
  • Page 4: Important Information And Health & Safety

    IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual.
  • Page 5: Components For Evoflame & E-Smart

    DS MANUAL ISS. 13 DS MANUAL ISS. 13 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
  • Page 6: Installation

    INSTALLATION INSTALLATION DS MANUAL ISS. 13 DS MANUAL ISS. 13 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
  • Page 7: Model Dimensions

    1056mm 558mm 355mm 530mm Lindstrom DS 1056mm 558mm 355mm 530mm Stora DS 864mm 1208mm 1002mm 535mm DS MANUAL ISS. 13 DS MANUAL ISS. 13 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
  • Page 8: Requirements And Checks

    INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following impor- tant requirements; • Consult a qualified professional to check the structure of the installation site. • The appliance must not be installed any- where that it may come into contact with water, i.e.
  • Page 9: Installation

    TOOLS REQUIRED • Tape Measure • Screwdriver • Pencil • PZ2 Screw Bit • Spirit Level INSTALLATION STEPS Remove the two bottom mounted transit brackets from both sides. You will not need these for the installation. Determine the finished height and position that you want the appliance to be located.
  • Page 10 Your plasterboard can now line up with the plaster kits on the edge of the appliance. Your installation is now complete and you can set up your logs. DS MANUAL ISS. 13 DS MANUAL ISS. 13 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
  • Page 11: Log Layouts

    LOG LAYOUTS LOG LAYOUTS DS MANUAL ISS. 13 DS MANUAL ISS. 13 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
  • Page 12 LOG LAYOUTS When you have your appliance installed you can set up your log sets. If your model comes with Chippings, Glass Stones and/or Vermiculite lay this on the fuel bed first, then continue with laying out your logs. The following images show an example of how you could lay them out.
  • Page 13: Installing/Removing The Front Glass

    INSTALLING / REMOVING THE FRONT GLASS Unscrew and remove the glass retainer panel. Apply the Suction Lifter to the glass and place the bottom edge in first, then angle the top edge into the appliance. Then replace the top retainer panel. Warning The Suction Lifter is provided to assist in moving...
  • Page 14: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING DS MANUAL ISS. 13 DS MANUAL ISS. 13 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
  • Page 15 Evoflame Only - LED Strip Replacement Scan the QR code to be taken to a video in our maintenance series. Please note; this video shows an old method of removing the front glass panel. Refer to page 13 for the new method. Fan Re-setting &...
  • Page 16: Warranty & Registration

    WARRANTY & WARRANTY & REGISTRATION REGISTRATION DS MANUAL ISS. 13 DS MANUAL ISS. 13 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1 EVONIC - 104 INSTRUCTION GUIDE TEMPLATE ISSUE 1...
  • Page 17 WARRANTY If this appliance should prove to be defective due to faulty design, materials or workmanship within 12 months of purchase, the product will be repaired free of charge, subject to the following conditions: The electric fire shall have been purchased and used solely within the UK and Ireland for domestic purposes and in accordance with the Users operating instructions.
