Summary of Contents for Evonic Fires E500

Page 1 English English BUILT-INS BUILT-INS Evoflame & E-Smart Evoflame & E-Smart INSTRUCTION MANUAL INSTRUCTION MANUAL E500 E500 E900 E900 Avesta Avesta E600 E600 E1000 E1000 Kallan Kallan E630 E630 E1030 E1030 Karlstad Karlstad E640 E640 E1250 E1250 Kiruna Kiruna E700 E700...
Page 2: Table Of Contents
CONTENTS EU Directives and UKCA Standards..............3 Important Information and Health & Safety............4 Components for Evoflame..................5 Components for E-Smart..................6 App Instructions....................7 E-Touch App Instructions (Evoflame Models)..........8 E-Smart Cloud App Instructions (E-Smart Models)........13 Pairing with Amazon Alexa................16 Pairing with Google Home................19 Installation......................
Page 3: Eu Directives And Ukca Standards
Particular requirements for room heaters Particular requirements for room heaters UKCA STANDARDS All Evonic Fires products are in conformity with the relevant UK Statutory Instruments All Evonic Fires products are in conformity with the relevant UK Statutory Instruments (and their amendments).
Page 4: Important Information And Health & Safety
IMPORTANT INFORMATION AND HEALTH & SAFETY When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following: • Read all of the instructions carefully before using the appliance, only use this appliance as described in this manual.
Page 5: Components For Evoflame
EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 6: Components For E-Smart
EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 7: App Instructions
APP INSTRUCTIONS APP INSTRUCTIONS E-Touch & E-Smart Cloud E-Touch & E-Smart Cloud EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 8: E-Touch App Instructions (Evoflame Models)
E-TOUCH APP INSTRUCTIONS (EVOFLAME MODELS) The E-Touch app is a Bluetooth app that can be used with both smart phones and tablet The E-Touch app is a Bluetooth app that can be used with both smart phones and tablet devices, and is available on both the Apple App Store and Google Play Store. devices, and is available on both the Apple App Store and Google Play Store.
Page 9 NAMING YOUR FIRE Single press on the Gear Symbol in Single press on the Gear Symbol in Single press on the Modify Name Single press on the Modify Name the top right of the Home Page. the top right of the Home Page. option.
Page 10 CHANGING LANGUAGE & UNITS Single press the Go Back button in Single press the Go Back button in Single press on the Setting button. Single press on the Setting button. the top left of the Home Page. the top left of the Home Page. You can now choose from English, You can now choose from English, To return to the Fire Connection...
Page 11 PROGRAMMING THE TIMER Single press the Time Set button Single press the Time Set button There are two types of timer you There are two types of timer you on the Home Page to begin on the Home Page to begin can programme.
Page 12 Scroll down the page to select either Heat Scroll down the page to select either Heat The Week/Common Mode Page will now The Week/Common Mode Page will now Low (750w), or Heat High (1.5kW). Low (750w), or Heat High (1.5kW). display your chosen settings.
Page 13: E-Smart Cloud App Instructions (E-Smart Models)
E-SMART CLOUD APP INSTRUCTIONS (E-SMART MODELS) The E-Smart Cloud app is a WiFi app that can be used with both smart phones and tablet The E-Smart Cloud app is a WiFi app that can be used with both smart phones and tablet devices, and is available on both the Apple App Store and Google Play Store.
Page 14 CONTROL OVERVIEW To adjust the desired temperature of your fire ensure that the heater is selected on the To adjust the desired temperature of your fire ensure that the heater is selected on the Home Page in the previous step. Then press, hold, and rotate the temperature dial to set Home Page in the previous step.
Page 15 PROGRAMMING THE TIMER Single press the clock icon on the Home Single press the clock icon on the Home Input your desired time in the Time box, Input your desired time in the Time box, Page to begin programming the Timer. Page to begin programming the Timer.
Page 16: Pairing With Amazon Alexa
PAIRING WITH AMAZON ALEXA Once your fire is installed, and switched Once your fire is installed, and switched Single press Skills & Games on the pop Single press Skills & Games on the pop on, download and open the Amazon on, download and open the Amazon up list.
Page 17 Enter the log in details that you Enter the log in details that you After a few moments your account will After a few moments your account will previously entered in the app set up previously entered in the app set up be linked, once this is done you can be linked, once this is done you can process, and single press Log In.
Page 18 ALEXA COMMANDS When using Alexa to control your appliance settings remember to substitute the words ‘the fire’ for whatever you have named your appliance. Turning the appliance On and Off. “Alexa, turn fire on.” “Alexa, turn fire off.” Turning the heater On and Off. “Alexa, set fire heater to auto.”...
Page 19: Pairing With Google Home
PAIRING WITH GOOGLE HOME Once your fire is installed, and switched Once your fire is installed, and switched Single press Set up Device on the pop Single press Set up Device on the pop on, download and open the Google on, download and open the Google up list.
Page 20 Type in Evonic Fires, single press Once in the evoflame log in page, enter Once in the evoflame log in page, enter search and then select the Evonic Fires search and then select the Evonic Fires the log in details that you previously log in details that you previously E-Smart icon.
Page 21 GOOGLE HOME COMMANDS When using Google Home to control your appliance settings remember to substitute the words ‘the fire’ for whatever you have named your appliance. Please note that the Google Home app cannot control the heater in the appliance. Turning the appliance On and Off.
Page 22: Installation
INSTALLATION INSTALLATION Evoflame & E-Smart Evoflame & E-Smart EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 23: Model Dimensions
MODEL DIMENSIONS The model shown in these drawings is an E1030, however the same processes apply to all Evoflame and E-Smart models. Scan the QR code for more detailed specification drawings. EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 24 Model Width Height Depth With With No glass Overall Overall glass optional Opening or side unit unit sides side panels panels E500 524mm 540mm 609mm 397mm 316mm E600 670mm 686mm 638mm 455mm 196mm E630 670mm 688mm 640mm 455mm 316mm E640...
Page 25: Installation Process
INSTALLATION PROCESS Evoflame or E-Smart Model Evoflame or E-Smart Model (GF2) (GF2) (GF) (GF) (GF3) (GF3) Front & Front & Open Open Glass Glass Front & Front & 1 Glass Side 1 Glass Side Fronted Fronted Fronted Fronted 2 Glass Sides 2 Glass Sides Fit 2 Side Panels Fit 2 Side Panels...
Page 26: Converting To Gf / Gf2 / Gf3
CONVERTING TO GF / GF2 / GF3 The appliance is shipped in the GF3 configuration, however most models can be converted to be GF or GF2 depending on your preference. GF Configuration Glass Fronted A single glass panel at the front of the appliance.
Page 27: Installing The Side Panels / Converting To Gf / Gf2
INSTALLING THE SIDE PANELS / CONVERTING TO GF / GF2 Unscrew and remove the plaster kits from the side/s of the appliance. Screw in the side panel/s, on one or both sides. EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 28: Requirements And Checks
INSTALLATION INSTALLATION REQUIREMENTS Before installing the appliance please read and take into account the following important requirements; • Consult a qualified professional to check the structure of the installation site. • These appliances have been designed to be installed into either a stud and plasterboard wall, or an existing chimney breast.
Page 29 CHECKS BEFORE INSTALLATION We recommend turning on the appliance before installation, connect the appliance to a power source using the provided electrical lead, and depress the right side of the rocker switch. Please note that on Evoflame models once the appliance is switched on, the lights will flash, this means the appliance is working and now ready to install.
Page 30: Installation
TOOLS REQUIRED • Tape Measure • Rear Wall Screws (Masonry type supplied) • Pencil • Top Mounted Bracket Screws x 6 (supplied) • Spirit Level • Top Mounted Bracket Wall Screws x 8 • Screwdriver (supplied) • PZ2 Screw Bit •...
Page 31 Determine the finished height and position that you want the appliance to be located. Then secure the wall bracket to the wall in the position you need using the wall plugs and screws provided. If you’re not securing the appliance to a masonry wall you will need to use the appropriate fixings.
Page 32 Screw the two top mounted brackets to the wall. You can now construct your stud wall/s around the appliance in the design of your choosing. When constructing the studwork, remember that the vents on the underside of the appliance need a minimum of 50mm clearance beneath them.
Page 33 Your plasterboard can now line up with the plaster kits on the edge of the appliance. Alternatively, the chrome side panels can be attached to the case with the magnets as shown below. Ensure that the magnets are positioned with the short side touching the case. EVONIC - 104 INSTRUCTION MANUAL ISS.
Page 34: Log Layouts
LOG LAYOUTS LOG LAYOUTS Evoflame & E-Smart Evoflame & E-Smart EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 35 1 x Small Woodland / Silver Birch 2 x Small Log Set E500 / E600 Open Fronted / E630 / E700 E600 / E700 Open Fronted / E730/ Thoren / Kallan...
Page 36 4 x Large Woodland / Silver Birch E2400 1 x Medium Split Woodland / Silver Birch Tyrell 1 x Small Split Woodland / Silver Birch Kiruna / Motala 2 x Small Split Woodland / Silver Birch Avesta 1 x Large Split Woodland / Silver Birch Linnea 1 x Small Split Woodland / Silver Birch &...
Page 37: Installing The Side Glass
INSTALLING THE SIDE INSTALLING THE SIDE GLASS PANELS GLASS PANELS EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 38 INSTALLING THE SIDE GLASS PANELS Unscrew and remove the top and bottom glass retainer panels. Slide in the side glass pieces. EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 39: Installing The Front Glass
INSTALLING THE FRONT INSTALLING THE FRONT GLASS PANEL GLASS PANEL EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 40 INSTALLING THE FRONT GLASS PANEL Apply the Suction Lifter to the glass and position the bottom edge of the glass first, then pivot the glass into the appliance. Then replace the top and bottom glass retainers. EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS.
Page 41: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Evoflame & E-Smart Evoflame & E-Smart EVONIC - 104 INSTRUCTION MANUAL ISS. 4 EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
Page 42 Evoflame Only LED Strip Replacement Scan the QR code to be taken to a video in our maintenance series. Please note; this video shows an old method of removing the front glass panel. Refer to page 25 of this instruction manual for the new method.
Page 43 REPORT A FAULT If you have any difficulties or problems with your appliance then please get in touch so that we can assist you. Please scan the QR code to be taken to our websites Report a Fault page, we will then be in touch with you shortly. EVONIC - 104 INSTRUCTION MANUAL ISS.
Page 44 CK Fires Ltd / Evonic Fires 1, Evonic House, Clifford Park, Clifford Lane, Stratford-on-Avon, CV37 8HW Tel: +44 (0)1789 263868 Fax: +44 (0)1789 293080 Email: sales@evonicfires.co.uk Follow us on: Instagram | Facebook | Twitter | LinkedIn @evonicfires EVONIC - 104 INSTRUCTION MANUAL ISS. 4...
