9. Controlling the Fan
Your fan was delivered to you with the included control
paired to your fan.
A: Light On/Off, Bright/Dim
B: Fan On/Off, Speed Up/Down
C: Season (Summer/Winter)
Air-Gap Switch: Pull tab to power off in case of emergency. Not
necessary for normal fan operation (only included with wall control).
NOTE: Your fan features 6 speeds. An audible tone will indicate when
the speed is increased or decreased. When the fan has reached the
minimum/maximum speed level the fan will beep twice.
NOTE: Pairing must be completed within 3 minutes of power
being applied to the fan receiver
Controlling Multiple Fans with Remote or Wall Controls
Your remote and wall controls are capable of controlling
multiple fans. A remote or wall control has the ability to control
an unlimited number of fans with the only limitation being the
Bluetooth® range of the control and fan.
Pairing a remote control or wall control to an additional fan(s) can
be performed in the same manner as described in the pairing section.
NOTE: Pairing must be completed within three (3) minutes of
powering the fan.
Synchronizing Control Across Multiple Fans
If you are controlling more than one fan with a remote control, there
is a possibility that their light state, fan state or fan direction can get
out of sync. To bring the fans/lights back into sync please follow the
instructions on the next page.
22 Renegade Instructions
9
Wall Control
* Air-Gap Switch only included
with wall control
9B
Fan On/Off
button for 4 seconds.
Fan On/Off: Press and hold
green and all connected fans will beep to indicate the message has been received. All
fans will turn off. This will bring all fans controlled by the remote into sync.
Light On/Off: Press and hold
flash
green and all connected fans will beep to indicate the message has been received. All
lights will turn off. This will bring all fans controlled by the remote into sync.
Fan Direction: Press and hold
flash green and all connected fans will beep to indicate the message has been
received. All fans will be set to summer mode (CCW rotation). This will bring all fans
controlled by the remote into sync.
F R- W 2 0 0 1
F R - W 2 0 01
9A
A
B
C
Air-Gap
Switch*
Summer Mode
Remote
Control
Light On/Off
Press and hold Press and hold
button for 4 seconds.
button for 4 seconds. The LED on the remote will flash
button for 4 seconds. The LED on the remote will
button for 4 seconds. The LED on the remote will
Winter Mode
(Counter-Clockwise) (Clockwise)
Fan Direction
Press and hold
button for 4 seconds.
Renegade Instructions 23
