StarTech.com RK4OD2 Quick Start Manual

19in Open Frame 2-Post Desktop Rack
Product IDs
RK4OD2
RK8OD2
Product Diagram
1
3
2
Component
• Feature Square Cage Nut Holes to mount your
1 equipment.
Vertical Rails
• Ranges from 4U to 8U according to the model.
2
Front Base Bracket • Stabilizes the frame and adds rigidity.
3 • Insert the Rubber Feet to protect the surface.
Rubber Feet Holes
• Used to connect the Vertical Rails, Front Base
4 Assembly Holes
Bracket, and Base Brackets together.
5 Base Brackets • Stabilizes the frame and adds rigidity.
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
5
4
*Product may vary from image
Function
Package Contents
• Left Base Bracket x 1
• Right Base Bracket x 1
• Left Vertical Rail x 1
• Right Vertical Rail x 1
• Front Base Bracket x 1
• M5x12 mm Assembly Screws x 8
• Rubber Feet x 4
• Quick-Start Guide x1
M6 Cage Nuts
Product ID
Quantity
RK4OD2 x 16
RK8OD2 x 32
Requirements
For the latest manuals, product information, technical specifications, and declarations
of conformance, please visit:
www.startech.com/RK4OD2
www.startech.com/RK8OD2
• Phillips head screwdriver
• Cage nut tool (Optional)
Warnings!
Read the entire quick-start guide and ensure the instructions are fully understood
before assembling and/or using this product.
Before adding equipment to this product, ensure this product has been properly
assembled.
Never operate this product if parts are missing or damaged.
Ensure the weight of the equipment does not exceed the weight capacity of this
product. If the weight capacity is exceeded, personal injury or damage to the
equipment are possibilities. These products can support the following weight:
88 lb (40 kg) for RK4OD2 and 110 lb (50 kg) for RK8OD2.
This product poses a tipping risk.
Quick-Start Guide
M6x12 mm Screws M6 Plastic
Quantity Washers Quantity
x 16 x 16
x 32 x 32
Manual Revision: August 8, 2022 12:39 PM
