Access Modular Controller 2
4.3
Opening the case
Notice!
i
To open the controller, first remove all pluggable connectors.
The controller's case consists of a top cover mounted with a two-point snap-in closure on a
chassis. To open the case, push down the two snap-ins with a screwdriver, then swing the
cover down.
Figure 4.3: Opening the controller´s case
Bosch Security Systems B.V.
Guide d'installation
Installing | en
15
2022-11 | V04 |
