Epic T20 FMTL24940 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model No. FMTL24940
Serial No.
The serial number is found in the
location shown below. Write the
serial number in the space above.
Serial Number Decal
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.–Fri., 6 a.m.–6 p.m. MST
CAUTION
Read all precautions and in-
structions in this manual before
using this equipment. Keep this
manual for future reference.
USER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Epic T20 FMTL24940

Summary of Contents for Epic T20 FMTL24940

  • Page 1 Model No. FMTL24940 Serial No. The serial number is found in the location shown below. Write the serial number in the space above. Serial Number Decal QUESTIONS? If you have questions, or if there are missing parts, we will guar- antee complete satisfaction through direct assistance from our factory.

  • Page 2: Table Of Contents

    LIMITED WARRANTY ............. . .Back Cover EPIC is a trademark of ICON Health & Fitness, Inc.

  • Page 3: Important Precautions

    Always listen for the page 9. To purchase a surge suppressor, see “chirp” and be prepared for speed and/or in- your local EPIC dealer or call 1-800-806-3651 cline changes. In some instances, the speed and order part number 146148.
  • Page 4 21. When using iFIT.com CDs and videos, you will void the warranty and may result in dam- can manually override the speed and incline age to the treadmill. settings at any time by pressing the speed DANGER: and incline buttons. However, when the next Always unplug the power “chirp”...

  • Page 5: Before You Begin

    Congratulations for selecting the revolutionary EPIC cluding holidays). To help us assist you, please note T20 treadmill. The EPIC T20 treadmill offers an im- the product model number and serial number before pressive array of features to make your home work- calling.

  • Page 6: Assembly

    ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Assembly can be completed using the included allen wrenches. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton.
  • Page 7 4. See step 1. While a second person holds the Uprights (95, 97), remove the two Upright Bolts (96). Slide the Uprights (95, 97) fully onto the brackets on the Frame (not shown). Be careful to avoid pinching your hands or the Wire Harness (not shown). Attach each Upright with four Upright Bolts (96) as shown.

  • Page 8: How To Use The Chest Pulse Sensor

    HOW TO USE THE CHEST PULSE SENSOR HOW TO PUT ON THE CHEST PULSE SENSOR each use, it may remain activated longer than nec- essary, draining the battery prematurely. The chest pulse sensor consists of two components: • Store the chest pulse sensor in a warm, dry place. the chest strap and the sensor unit (see the drawing Do not store the chest pulse sensor in a plastic bag below).

  • Page 9: Treadmill Operation

    Adapter the right). To purchase a surge suppressor, see Surge Suppressor your local EPIC dealer or call 1-800-806-3651 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge sup- pressor (TVSS).
  • Page 10 Note: If there is a thin sheet of clear plastic Matrix on the face of the console, remove it. Main Display FEATURES OF THE CONSOLE audio cable, you can connect the treadmill to your home stereo, portable stereo, or computer and play special The console offers an impressive array of features to iFIT.com CD programs (CDs are available separately).
  • Page 11 Insert the key into the console. CAUTION: Before operating the Find the key console, read the following precautions. and the clip • Do not stand on the walking belt when turn- and attach ing on the power. the clip to the Clip waistband of •...
  • Page 12 Change the incline of the treadmill as desired. HOW TO USE THE MANUAL MODE To change the incline of the treadmill, press the Insert the key into the console. INCLINE + and – but- tons. Each time a button See GETTING STARTED on page 11. is pressed, the incline will change by 0.5%.
  • Page 13 Distance—The center To reset the displayed time, distance, and section of the main dis- Calories at any time, press the RESET button. play will show the dis- tance that you have Measure your heart rate if desired. walked or run. To use the chest pulse sensor, see page 8.
  • Page 14 Each program is divided into several time segments HOW TO USE PRESET PROGRAMS of different lengths. The main display will show both the time remaining in the program and the time remaining in the current segment of the pro- Insert the key into the console. gram.
  • Page 15 darken in those columns as well.) Important: HOW TO USE PULSE-DRIVEN PROGRAMS When the next segment of the program begins, the treadmill will automatically adjust to the speed and incline settings for the next segment. Pulse-driven programs automatically control the speed and incline of the treadmill to keep your heart rate near To stop the program at any time, press the STOP a target level while you exercise.
  • Page 16 Each pulse-driven program is divided into one- Enter your age. minute segments. The main display will show both the time remaining in the program and the time re- You must enter your age to use a pulse-driven maining in the current segment of the program. program.
  • Page 17 Press the START button to start the program. HOW TO USE THE FITNESS TEST PROGRAM When the button is pressed, the main display will The fitness test program measures your relative fitness show the words LEVEL 1, indicating that the first level.
  • Page 18 Note: The SPEED and INCLINE buttons will not HOW TO CONNECT THE TREADMILL TO YOUR function while the fitness test program is selected. If CD PLAYER, VCR, OR COMPUTER your pulse is not detected during the program, the letters PLS will flash in the main display. If your pulse is not detected at the end of any four-minute To use iFIT.com CDs, the treadmill must be connected level, the fitness test program will end and the...
  • Page 19 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT YOUR HOME STEREO Note: If your stereo has an RCA-type AUDIO OUT Note: If your stereo has an unused LINE OUT jack, jack, see instruction A below. If your stereo has a see instruction A below.
  • Page 20 HOW TO CONNECT YOUR COMPUTER HOW TO CONNECT YOUR VCR A. Plug one end of the audio cable into the indicated Note: If your VCR has an unused AUDIO OUT jack, jack on the left side of the console. Plug the other see instruction A below.
  • Page 21 If the speed or incline settings are too high or too HOW TO USE IFIT.COM CD AND VIDEO low, you can manually override the settings at any PROGRAMS time by pressing the SPEED or INCLINE buttons on the console. However, when the next “chirp” is heard, the speed and/or incline will change To use iFIT.com CDs or videocassettes, the treadmill to the next settings for the program.
  • Page 22 Return to the treadmill and stand on the foot HOW TO USE PROGRAMS DIRECTLY FROM rails. Find the clip attached to the key and slide OUR WEB SITE the clip onto the waistband of your clothes. When the on-screen countdown ends, the program Our Web site at www.iFIT.com allows you to access will begin and the walking belt will begin to move.
  • Page 23 THE INFORMATION MODE/DEMO MODE The right side of the main dis- play will show an E for The console features an information mode that keeps English miles or an M for track of the total number of hours that the treadmill has metric kilometers.

  • Page 24: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps outlined in this section. Find any symptoms that apply, and follow the steps listed. If further assistance is needed, please call Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time. 1.
  • Page 25 4. SYMPTOM: THE WALKING BELT IS OFF-CENTER a. If the walking belt has shifted to the left: Remove the key and unplug the power cord. Using the included allen wrench, turn each roller adjustment bolt 1/4 of a turn in the direction shown.
  • Page 26 7. SYMPTOM: THE SURFACE OF THE WALKING PLATFORM IS DAMAGED a. Both sides of the walking platform are designed to be used as walking surfaces. If the surface becomes damaged, or if there is any wood showing through the coating, the walking platform can be turned over. The walking platform typically needs to be turned over after approximately 6,000 to 7,500 miles.

  • Page 27: Exercise Guidelines

    EXERCISE GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed and incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian.

  • Page 28: Part List

    PART LIST—Model No. FMTL24940 R1003B To locate the parts listed below, see the EXPLODED DRAWING on pages 30 and 31. Key No. Qty. Description Key No. Qty. Description Motor Hood Pulley Nut Hood Screw Motor Bolt Outlet Cover Screw Pulley Washer Hood Mounting Clips Power Wire Harness Rear Foot...

  • Page 29: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give the following information: • The MODEL NUMBER OF THE PRODUCT (FMTL24940) • The NAME OF THE PRODUCT (EPIC T20 treadmill) • The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual) •...

  • Page 32: Limited Warranty

    LIMITED WARRANTY WHAT IS COVERED—The entire EPIC T20 treadmill (“Product”) is warranted to be free of all defects in material and workmanship. WHO IS COVERED—The original purchaser or any person receiving the Product as a gift from the original purchaser.
