Hanskamp PowerSpray Installation And Operating Instructions Manual

Liquids spraying system
Hide thumbs

Advertisement

Quick Links

Download this manual
PowerSpray
039-011-000 up to 039-366-000
Vernevelsysteem voor vloeistoffen
Liquids spraying system
Zerstäubungssystem für Flüssigkeiten
Vaporisateur de liquides
&
EN
Installation and operating instructions
Article number: 010-271-000
Date: november 2016
Doetinchem,
Version 1.1– Translation of original manual
The Netherlands
www.hanskamp.nl/en
According to Annex 1 chapter 1.7.4 Machine Guideline 2006/42/EC

Advertisement

loading
Need help?

Need help?

Do you have a question about the PowerSpray and is the answer not in the manual?

Questions and answers

Related Manuals for Hanskamp PowerSpray

Summary of Contents for Hanskamp PowerSpray

  • Page 1 PowerSpray 039-011-000 up to 039-366-000 Vernevelsysteem voor vloeistoffen Liquids spraying system Zerstäubungssystem für Flüssigkeiten Vaporisateur de liquides & Installation and operating instructions Article number: 010-271-000 Date: november 2016 Doetinchem, Version 1.1– Translation of original manual The Netherlands www.hanskamp.nl/en According to Annex 1 chapter 1.7.4 Machine Guideline 2006/42/EC...

  • Page 2: Manual Contents

    Toepasselijkheid The table below shows the type numbers of the PowerSpray for which this manual is applicable. The type number can vary, according to the type of control of the Power- Spray, the number of liquid types, as well as the number of feeding stations/milking ro- bots in which the liquid has to be sprayed.
  • Page 3 The PowerSpray of Hanskamp offers the perfect solution for this situation. It consists of a so called PompUnit and a SprayUnit. With this, various soluble additives or medicines can be sprayed over the nose of the cow, and in this way onto the nose’s mucous mem-...
  • Page 4 PowerSpray knows all the related SAFETY information in this manual. YOU are the key to safety. Good safety practices protect you and the people around you.
  • Page 5 PowerSpray.  Only trained persons are permitted to operate the PowerSpray. A first-aid kit must be available near the PowerSpray. Store in a highly visi- ble place.  A carbon dioxide or foam fire extinguisher must be available near the PowerSpray.
  • Page 6 Vernevelsysteem, Zerstäubungssystem, liquids spraying system, vaporisateur de liquides 2.3.5 Maintenance Safety  Read and understand the applicable manual and all safety signs before you connect power supplies to operate or adjust the PowerSpray.  Only trained persons are permitted to maintain the PowerSpray. ...

  • Page 7: Installation Instructions

    Transport en storage: Delivery specifications The PowerSpray will be stored in a sealed box. This box is sealed with tape and the in- The box contains: side of the box is covered with protection foil to prevent the PowerSpray from damage.
  • Page 8 Before installing anything, check if all parts are available using the parts list at the back of this manual. For this, please refer to Annex 1 and 2. Determine where and at what height the PowerSpray PompUnit should be in- stalled. Users that want to spray a solution at multiple locations, are advised to place the PompUnit at a central location in the barn.
  • Page 9 PumpUnit will only be shortly active, just after the SprayUnit has been activated by the feeding system. Calibration Calibrating the PowerSpray system is done using the following steps, according to the connected feeding system: First, it is needed to bleed the air out of the SprayUnit. keep a test-tag of the corresponding feed type in front of the tag reader.
  • Page 10 For your own safety, consult the safety information of the to be used fluid, about how to safely use this fluid. When using the PowerSpray in combination with this fluid, al- ways take into account the described precautions. Hanskamp is not liable for any false use of fluids in combination with the PowerSpray.
  • Page 11 Translations in other languages, than Dutch, use the Dutch installation and operating instruction as source document. Hanskamp AgroTech accepts no liability for differences between translations. If there are any doubts about the content and the accuracy of the translated installation and operating instructions, the Dutch installation and operating instructions is the authoritative document.
  • Page 12 NEN-EN-ISO 12100 NEN-5509 We call your attention to the fact where the PowerSpray has not been installed or has not been installed in accordance with safety measures in these installation and oper- ating instructions this declaration of stipulations is null and void and so no rights can be derived from this declaration.
  • Page 13 Unscrew the spray nozzle and clean the inside of the The filter of the spray nozzle is clog- nozzle. It is advised to use compressed air, to blow ged. out any blockings in the nozzle. 13 - 22 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 14 PowerSpray Vernevelsysteem, Zerstäubungssystem, liquids spraying system, vaporisateur de liquides 14 - 22 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 15 PowerSpray Vernevelsysteem, Zerstäubungssystem, liquids spraying system, vaporisateur de liquides Annex 2: Individual parts of PowerSpray PompUnit (table goes for an installation with 1 PompUnit) Article number Description Amount 003-920-000 PowerSpray PompUnit 001-162-000 Hose clip mini 6mm ev 001-154-001 Pressure sensor PowerSpray PompUnit G1/4 EPDM incl. seal, 10 mm thread 001-200-000 Push-in coupling 1/8”x 6mm threaded outside...
  • Page 16 PowerSpray Vernevelsysteem, Zerstäubungssystem, liquids spraying system, vaporisateur de liquides 16 - 22 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 17 PowerSpray Vernevelsysteem, Zerstäubungssystem, liquids spraying system, vaporisateur de liquides 17 - 22 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 18 Wago connector, 2 connections 002-037-000 Torx bolt M4x5 T20 003-558-000 Directly actuated valve 2mm (mini) 1/4” 003-913-000 PowerSpray mounting plate for PCB housing M4 1,5mm RVS 003-926-000 PowerSpray extremely fine spray nozzle 1/4” 003-927-000 Seal plug PVC 003-928-000 Vent valve Ø4 010-134-000 Sticker serial no.
  • Page 19 Cable 6x0,34mm l=4,5m RIM time-controlled 002-037-000 Torx bolt M4x5 T20 003-558-000 Directly actuated valve 2mm (mini) 1/4” 003-913-000 PowerSpray mounting plate for PCB housing M4 1,5mm RVS 003-926-000 PowerSpray extremely fine spray nozzle 1/4” 003-927-000 Seal plug PVC 003-928-000 Vent valve Ø4 010-134-000 Sticker serial no.
  • Page 20 PowerSpray Vernevelsysteem, Zerstäubungssystem, liquids spraying system, vaporisateur de liquides Annex 5: Optional parts 003-919-000: Mounting plate for PowerSpray PompUnit Article number Description Amount 001-639-000 Metal screw M4x10 a2 cross-recessed 001-856-000 Self-locking bolt M4 a2 003-919-001 Mounting plate stainless steel 1,5mm 004-125-000 Wire bracket 1¼"...
  • Page 21 PowerSpray Vernevelsysteem, Zerstäubungssystem, liquids spraying system, vaporisateur de liquides Annex 6: PompUnit dimensions (mm) 21 - 22 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 22 Vernevelsysteem, Zerstäubungssystem, liquids spraying system, vaporisateur de liquides Hanskamp AgroTech B.V. Broekstraat 17 7009 ZB Doetinchem The Netherlands Please also visit: Tel: +31 (0)314 - 393 797 Fax: +31 (0)314 - 393 826 www.hanskamp.nl/en 22 - 22 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
