PipeFeeder
24VAC & 12-24VDC
EN
Installation and operating instruction
Article number: 1847
Datum: August 2014
Zelhem,
Version 2.2 - Translation of Original Instructions for use
The Netherlands
According to Annex 1 Chapter 1.7.4 Machine guideline 2006/42/EG
www.hanskamp.nl

Advertisement

loading
Need help?

Need help?

Do you have a question about the PipeFeeder and is the answer not in the manual?

Questions and answers

Related Manuals for Hanskamp PipeFeeder

Summary of Contents for Hanskamp PipeFeeder

  • Page 1 PipeFeeder 24VAC & 12-24VDC Installation and operating instruction Article number: 1847 Datum: August 2014 Zelhem, Version 2.2 - Translation of Original Instructions for use The Netherlands According to Annex 1 Chapter 1.7.4 Machine guideline 2006/42/EG www.hanskamp.nl...

  • Page 2: Manual Contents

    Your PipeFeeder may comprise improvements, features or options that are not covered in this manual. Applicability The table below shows the type numbers of the PipeFeeder for which this manual is appli- cable. Model designation...
  • Page 3 FeedStation, robot or in the mil- king parlor. The information in this manual is for farmers and technicians.  Dairy farmers use the information to test and adjust the PipeFeeder or to list overviews.  Technicians use the information to install and setup the PipeFeeder.
  • Page 4 PipeFeeder knows all the related SAFETY information in this manual. YOU are the key to safety. Good safety practices protect you and the people around you.
  • Page 5  Replace any damaged electrical lines, conduits, switches and components imme- diately.  Isolate the electrical power supply before you open the lid of the PipeFeeder to work on the electrical system. 2.3.3 Installation Safety  Read and understand the instructions in this manual.
  • Page 6  Switch off the electrical power supply by taking plug out of the power point and secure the plug before you clean or do maintenance on the PipeFeeder.  Wear protective clothing and safety goggles when you do work on the pneumatic system.

  • Page 7: Installation Instruction

    General description: Hanskamp’s PipeFeeder is an electric feed dosing system developed for feeding concen- trates in pellet form (Pic. 1) PipeFeeder is designed for the supply of concentrate, either linked to the feed computer and used for milking stall feeding.
  • Page 8 The user and installer are responsible for the safe operation and maintenance of the Pipe- Feeder. Safety stickers are used to ensure safety in and around the PipeFeeder. These stickers must be placed correctly. Information about which stickers should be attached where can be found further on in these instructions for installation and use (for example Fig.
  • Page 9 5. Using the supplied membrane grommet (item no. 1947), fit the cable through the lid of the PipeFeeder. To do this, drill a hole (Ø 16 mm) at the desired position in the lid. Then connect the other end of the cable to the desired output of the control unit.
  • Page 10 Otherwise hazardous situations can emerge (pic. 4). 9. The PipeFeeder has fully electrical operation. The motor drives the axis that turns a scoop mechanism at the bottom of the stainless steel pipe (Ø129 x 2mm). This mech- anism delivers the feed. If a switch is used to control several dosing units at the same time, such asl on each side of the parlour (milking stall feeding), then several Pipe- Feeder dosing units can be connected to a single feeding line.
  • Page 11 Cleaning Clean the PipeFeeder regularly with a moist cloth. Do not spray water under the hood or in the stock pipe. To guarantee the equipment functions correctly make sure the exit point is clean and stays clean.
  • Page 12 No part of this publication may be reproduced or made public without prior permission in writing from Hanskamp AgroTech BV. Although this publication was put together with the utmost care, Hanskamp AgroTech is not liable for any damage that might arise due to errors or gaps in this publication.
  • Page 13 NEN-EN-IEC 60204-1 NEN-EN-IEC 13849-1 We call your attention to the fact where the PipeFeeder has not been installed or has not been installed in accordance with safety measures in these installation and oper- ating instructions this declaration of stipulations is null and void and so no rights can be derived from this declaration.
  • Page 14 7) be broken. Constipation by, for example wood or Remove the PipeFeeder off the wall and sha- plastic. ke it empty. The rotor can be rotated by hand when it is empty.
  • Page 15 Pipefeeder 24VAC & 12-24VDC Annexes Hanskamp can supply the following types of dosing units: 27321 Art. Nr.: Lengte: Motor: Product: Color: Color: 27 = PipeFeeder 0 = Extra short L= 821 mm 1 = 1650 24VDC 28 rpm SolidState++ (Anti-spill) DV...
  • Page 16 It is possible to reorder loose components from your supplier for maintenance, or for any other reason. Please use the item numbers shown below on the drawing. 27000 PipeFeeder DC Fig. 8 16 - 20 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 17 Pressure plate 90° resistor. (GEA/Westfalia) 1934 Connector DC motor 1034 Tap bolt M6x12 ad DIN 933 1937 Sticker CE PipeFeeder with 1366 Spring Washer M6 a2 DIN 137B serial number 1440 Silver motor 40rpm 24V DC, without cable. 1939 Assembly bottom plate com-...
  • Page 18 Pipefeeder 24VAC & 12-24VDC Installation dimensions: Visit us on: 18 - 20 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 19 Pipefeeder 24VAC & 12-24VDC 19 - 20 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 20 Pipefeeder 24VAC & 12-24VDC Hanskamp Arendsenweg 7 7021 PC Zelhem The Netherlands Tel: +31 (0)314 - 393 797 Fax: +31 (0)314 - 393 826 www.hanskamp.nl 20 - 20 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
