Hanskamp PipeFeeder Dump Installation Instruction

Carousel feeding system.
Hide thumbs

Advertisement

Quick Links

Download this manual
PipeFeeder Dump
029-019-000 & 029-049-000
Carrousel voersysteem
Carousel feeding system
Karussell-Fütterungssystem
Système d'alimentation carrousel
EN
Installation instruction
Article number: 010-273-000
Date: November 2017
Doetinchem,
Version 1.1 - Translation of Original Instruction for use
The Netherlands
According to Annex 1 Chapter 1.7.4 Machine guideline 2006/42/EG
www.hanskamp.nl/en

Advertisement

loading
Need help?

Need help?

Do you have a question about the PipeFeeder Dump and is the answer not in the manual?

Questions and answers

Related Manuals for Hanskamp PipeFeeder Dump

Summary of Contents for Hanskamp PipeFeeder Dump

  • Page 1 PipeFeeder Dump 029-019-000 & 029-049-000 Carrousel voersysteem Carousel feeding system Karussell-Fütterungssystem Système d’alimentation carrousel Installation instruction Article number: 010-273-000 Date: November 2017 Doetinchem, Version 1.1 - Translation of Original Instruction for use The Netherlands According to Annex 1 Chapter 1.7.4 Machine guideline 2006/42/EG...

  • Page 2: Manual Contents

    All information in this manual has been compiled with care. Hanskamp shall not be liable for errors or faults in this manual. The recommendations are meant to serve as guidelines.
  • Page 3 The benefit? Faster milking with signifi- cantly less concentrate. Hanskamp's Dump is supplied with 1 limit switch as standard. The switch enables the Dump to release the feed at exactly the right time. The Dump is also equipped with the ingenious anti-spill system.
  • Page 4 Do not modify the equipment in any way. Unauthorized modification may impair the function and/or safety and could affect the life of the equipment, and persons. • Only use approved parts, and make sure they are only installed by authorized tech- nicians. 4 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 5 Before the electrical supply is attached to the Dump, make sure all parts are tight and that all parts are in goood conditions. • Contact your nearest milking equipment dealer if you have any questions. 5 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 6 General safety messages appear in this safety messages section. Specific safety messages are in applicable parts of this manual when potential ha- zards may occur if the instructions or procedures are not followed. 6 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 7 1x PVC Ø125 L=850mm fall tube, Art.No.: 011-163-000 Type descriptions, located on the side of the tube, just above the motor Serial Number Article number Product descriptions Address marking Location of sticker auto-start 7 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 8 • Keep the safety abrasives that could damage the safety stickers. • Replace missing or illegible safety stickers. Safety stickers are available by Hanskamp. Always use the Article numbers in correspon- dence. 8 - 23 Hanskamp AgroTech B.V. (the Netherlands)
  • Page 9 The tab ensures that the valve can always move freely. The PVC pipe pre- vents access to the moving parts (valve) in the drop tube. (Fig. 6). 001-955-000 011-163-000 9 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 10 PipeFeeder HighSpeed. The slot is used to position the PipeFeeder correctly, to prevent the PipeFeeders from dispensing into each other when using two types of feed. (Fig. 9 & 10). 001-902-000 10 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 11 Dump (Art. No. 011-163-001). See also fig. 11. Drill 2 extra holes (4.2mm) on both sides of the PipeFeeder Dump (fig. 12). Slide the PVC tube in the upper side of the Dump, in such a way that both up- per sides of the tubes are even.
  • Page 12 The entire supply in the drop tube will be released into the feed trough at once. If you do not have 24V AC/DC available, order the Hanskamp PowerU- nit 24VDC 10A with power boost (Art. no.: 002-812-000).
  • Page 13 Please note! Do not spray with high pressure in or on the Dump. This can cause blockage. Disassembly In case of disassembly all parts must be separated by material type for processing through a suitable waste management system. 13 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 14 No part of this publication may be reproduced or made public without prior permission in writing from Hanskamp AgroTech BV. Although this publication was put together with the utmost care, Hanskamp AgroTech is not liable for any damage that might arise due to errors or gaps in this publication.
  • Page 15 The Netherlands, Doetinchem 15-12-2016 H.J. Hanskamp 15 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 16 The rotor can be rotated by hand when it is empty. Dump isn’t anti spill. Dump isn’t set. For set up see page 9 Dump doesn’t distribute the Calibration is incorrect. Calibrate the controller proper amount. 16 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 17 Carrousel voersysteem—Carousel feeding system—Karussel-Fütterungssystem—Système d’alimentation carrousel Loose components: It is possible to reorder loose components from your supplier for maintenance, or for any other reason. Please use the item numbers shown below on the drawing. 001-755-000 17 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 18 011-145-004 RIM motor complete 28RPM 2kg. for PF-Dump Pipe variation list: Art no. Description Qty, 011-152-001 Stainless steel Pipe Ø129x2 for Dump 1Kg. complete 011-152-004 Stainless steel Pipe Ø129x2 for Dump 4Kg. complete 18 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 19 Dump Carrousel voersysteem—Carousel feeding system—Karussel-Fütterungssystem—Système d’alimentation carrousel Individual parts of PipeFeeder Dump Container (011-165-000) 19 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 20 011-158-000 Slide bearing nylon black 10x12x21mm for Dump 011-159-000 Shaft with gear complete for Dump 011-163-000 PVC tube Ø125, 850mm black for Dump 011-163-001 PVC tube Ø125, 100mm black for Dump 20 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 21 Dump Carrousel voersysteem—Carousel feeding system—Karussel-Fütterungssystem—Système d’alimentation carrousel Installation dimensions 1Kg. Version: 21 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 22 Dump Carrousel voersysteem—Carousel feeding system—Karussel-Fütterungssystem—Système d’alimentation carrousel Installation dimensions 4Kg. version: Visit us on: 22 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
  • Page 23 Dump Carrousel voersysteem—Carousel feeding system—Karussel-Fütterungssystem—Système d’alimentation carrousel Hanskamp AgroTech B.V. Broekstraat 17 7009 ZB Doetinchem The Netherlands Tel: +31 (0)314 - 393 797 Fax: +31 (0)314 - 393 826 www.hanskamp.nl/en 23 - 23 Hanskamp AgroTech B.V. (the Netherlands) www.hanskamp.nl/en...
