L'port
004-000-000
Sluithek
Closing Gate
Schließbügel
Porte Arrière Automatique
EN
Installation and Operating Instructions
Product number: 010-079-000
Date: October 2023
Doetinchem,
Version 2.8 - Translation of original Instructions for use
The Netherlands
According to Appendix 1 Chapter 1.7.4 of the Directive 2006/42/EC on machinery
www.hanskamp.com
Advertisement
Related Manuals for Hanskamp L'port
Summary of Contents for Hanskamp L'port
- Page 1 Closing Gate Schließbügel Porte Arrière Automatique Installation and Operating Instructions Product number: 010-079-000 Date: October 2023 Doetinchem, Version 2.8 - Translation of original Instructions for use The Netherlands According to Appendix 1 Chapter 1.7.4 of the Directive 2006/42/EC on machinery www.hanskamp.com...
- Page 2 All information in this manual has been compiled with care. Hanskamp shall not be liable for errors or faults in this manual. The recommendations are meant to serve as guide- lines.
- Page 3 The L'port closing gate of Hanskamp ensures that every single cow can eat her portion of concentrated feed in peace and you know that the feed goes to the right cow. The L'port closing gate is very simple to install with any type of out of parlour feeding station, includ- ing those with shorter side bars.
-
Page 4: Safety Instructions
• Only use original spare parts, and make sure that they are fitted by author- ised technicians. 4 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com... - Page 5 Before connecting the L’port to the power supply, make sure that all parts are properly tightened and that all cables and mountings are in good condi- tion. • If you have any other questions, please contact your milking technology dealer. 5 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 6 Correct adjustment can be found in relevant installation and user instruction. Warning! Make sure the cylinder is never mounted under radial forces. The cylinder can handle only axial forces on the piston rod. 6 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 7 Installation and Operating Instructions General description The L’port closing gate from Hanskamp is a pneumatically supplied gate that is de- signed to close the out of parlour feeding station for cows. The L’port closing gate must be attached parallel to the feed motors from all the feed sorts in de out of par- lour feeder.
- Page 8 Do not use solvents or abrasives that could damage safety stickers. • Replace missing or illegible safety stickers. Safety stickers are available from Hanskamp. Always use the product num- bers in correspondence. 1703 Warning sticker Put the supplied stickers on...
- Page 9 Should this not be the case, adjust the height of the standing leg tubes again. 9 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 10 In case of a power breakdown the L’port closing gate opens automatically. If there is no 24 Volts available, then order item number 2812 Hanskamp PowerUnit 10A 24VDC. Please note! Cable to be installed out of cow’s reach.
- Page 11 ‘Open’ (fig. 10.f), so that the cows can get used to the new installation. After this week the installation can be put into operation, by placing the switch (fig. 10.f.) to ‘Auto’. The sound level always equals 70 dB (A) or less. 11 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 12 These compressed air regulations can be consulted at www.hanskamp.com. The warranty does not apply to consequential damages unrelated to the machine itself. All systems have been tested, However, in the event of defects, Hanskamp AgroTech BV cannot be held responsible for consequential damage. 12 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 13 No part of this publication may be reproduced or made public without the prior written consent of Hanskamp AgroTech BV. Although this publication has been compiled with the greatest care, Hanskamp AgroTech BV is not liable for any damage that may arise d ue to any errors or omis- sions it might contain.
- Page 14 If the L’port is not connected and the prescribed safety instructions are not used, this Declaration of Conformity is not applicable and no rights can be derived from this decla- ration. Doetinchem, the Netherlands, 17-10-2023 H.J. Hanskamp 14 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 15 Sluithek - Closing gate - Schließbügel - Porte arrière automatique Appendix Hanskamp can supply the following types of L’port closing gates: 4030 L’port closing gate universal, fits on all types of out of parlour feeders. 4032 L’port closing gate XL (extended back gate), fits on DeLaval FSC40(0), FP200 &...
- Page 16 It is possible to reorder loose components from your supplier for maintenance, or for any other reason. Please use the item numbers as shown on the drawings (expl. Views). 4030 L’port closing gate 004-040-000 Cylinder set 4032 L’port closing gate XL 16 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 17 L’port Sluithek - Closing gate - Schließbügel - Porte arrière automatique 17 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 18 004-119-000 Cover L’port LLDPE/MDPE red 004-107-000 Assembly plate cylinder 004-131-000 Cover L’port LLDPE/MDPE orange 004-123-000 Box 40 Article only available in L’port Universal 4030. Article only available in L’port XL (longer extended element 4032). 18 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
- Page 19 Sluithek - Closing gate - Schließbügel - Porte arrière automatique Hanskamp AgroTech BV Broekstraat 17 7009 ZB Doetinchem Also take a look at: The Netherlands Tel: +31 (0)314 - 393 797 Fax: +31 (0)314 - 393 826 www.hanskamp.com 19 - 18 Hanskamp AgroTech BV (The Netherlands) www.hanskamp.com...
